Research on Double-Face Online Dynamic Balance Technology of Machine Tool Spindle

Abstract:

Based the principle of online dynamic balance device with balancing disks, the design method of embedded double-face online dynamic device was proposed. Balancing disks could be disengaged from the spindle by Hydraulic system, and the rotating speed of the disengaged disk was kept steady and under the speed of the spindle by friction torque. The systems of signal acquisition, signal analysis and control, hydraulic pressure were designed. The feasibility was proved and analyzed by examples.

• Periodical: Applied Mechanics and Materials (Volumes 44-47)
• Pages: 112-116
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.44-47.112
• Online since: December 2010
• Authors: Shi Hai Zhang, Liang Sheng Wu, Xian Bin Teng
• Keywords: Balance Disk, Influence Coefficient, Machine Tool Spindle, Online Dynamic Balance

References

[1] Liangsheng Wu, Jiangbo He, Yunxi Zhang etal: Journal of Beijing University of Technology Vol. 33(2007), p.1233～1238, in Chinese.

[2] Zhengsong Zhang, Shangxin Fu, Guanping Feng etal: Vibration Monitor and Fault Diagnosis of Rotating Machinery(Mechanical Industry Press. Beijing 1991), in Chinese.

[3] Shihai Zhang, Liangsheng Wu, Dashuai Zhou: Modular Machine Tool & Automatic Manufacturing Technique Vol. 10(2009), p.79~81, in Chinese.

[4] Yie Zhong, Yanzong He, Zheng Wang etal: Rotor Dynamics(Tsinghua university Press. Beijing 1987), in Chinese.
