Research on Guarantee Equipment for Setting Load of Hydraulic Supports

Abstract:

To solve the shortage of setting load of hydraulic support, this paper puts forward a computer simulation method. The reason for the shortage of setting load is firstly analyzed by simulating the pressure curve of prop’s lower chamber and the displacement curve of movable prop. It can be found that even prop lower chamber is supplied with fluid continuously, the pressure won’t reach to the pressure of pumping station, and the setting load also can’t be achieved. Secondly, the principle of auto-pressurized guarantee equipment for setting load is present. Only acting on one displacement, the pressurized valve can reach the pressure of pumping station. Simulation result also indicates that it can meet the requirement of setting load in a short time after the top beam reaches to the roof.

• Periodical: Applied Mechanics and Materials (Volumes 44-47)
• Pages: 2021-2025
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.44-47.2021
• Online since: December 2010
• Authors: Xin Zhang, Jian Wu Zhang, Li Rong Wan, Meng Zang
• Keywords: Auto-Pressurized, Guarantee Equipment, Hydraulic Support, Setting Load, Simulation

References

[1] Yixin Liu: Coal Science and Technology Vol. 26 (1998), pp.15-17.

[2] C.G.M. Merriman: Coal International Mining and Quarry World Vol. 251(2003), pp.161-164.

[3] Kaixuan Xiong: Journal of Jiaozuo Institute of Technology Vol. 16 (1997), pp.28-32.

[4] Yongjun Bai: Coal Vol. 17 (2008), pp.34-36.

[5] Ziming Kou and Lishan Shen: Coal Science and Technology Vol. 23 (1995), pp.8-9.

[6] Ziming Kou and Lishan Shen: Journal of the China Coal Society Vol. 21 (1996), pp.196-200.

[7] Hongjian Li, Xingliang Sun and Pingwu Shi: Journal of Hebei Institute of Architectural Science and Technology Vol. 14 (1997), pp.20-24.

[8] Pingmei Ming, Le Deng and Shengqi Yang: Journal of Jiaozuo Institute of Technology Vol. 21 (2002), pp.153-156.
