Finite Element Analysis of Ballastless Track Rail-Floating Slab’s Dynamic Characteristics

Abstract:

By using the finite element analysis software ANSYS, a three-dimensional dynamic finite element model of ballastless track rail –floating slab was established. The model takes into account of the track irregularity case, the analysis the dynamic response characteristics of the rail and floating slab under the vertical force in the track structure. The results showed that: when the train load goes through the line, the dynamic response of the rails and floating slabs gradually increases to maximum and then decreases; the maximum response displacement of rail is at 0.625mm ~ 0.75mm and the maximum response acceleration values is in between 5000m/s2~6000 m/s2; the maximum response displacement value of floating slab is about 0.25mm, the maximum response acceleration value is between 0.8 m/s2~1.2m/s2.

You might also be interested in these eBooks

Frontiers of Manufacturing and Design Science

View Preview

Info:

Periodical:

Applied Mechanics and Materials (Volumes 44-47)

Pages:

3907-3911

DOI:

https://doi.org/10.4028/www.scientific.net/AMM.44-47.3907

Citation:

Cite this paper

Online since:

December 2010

Authors:

Lin Ya Liu, Jin Wang, Rui Lv

Keywords:

Acceleration, Ballastless Track, Displacement, Dynamic Response, Track Irregularity

Export:

RIS, BibTeX

Price:

Permissions CCC:

Request Permissions

Permissions PLS:

Request Permissions

Сopyright:

Citation:

References

[1] V. V. Krylov, A. R. Dawson, M. E. Heelis, A. C. Collop. Rail movement and ground waves caused by high-speed trains approaching track-soil critical velocities [J]. Part F, Journal of rail and rapid transit, 2000, 214(2), p: 107-116.

DOI: 10.1243/0954409001531379

Google Scholar

[2] V.V. Krylov. Ground Vibration Boom from High-Speed Trains [J]. Journal of Low Frequency Noise & Vibration, 1999, 18(4), p: 207-218.

DOI: 10.1177/026309239901800405

Google Scholar

[3] LeiX, Noda N A. Analyses of dynamic response of vehicle and track coupling system with random irregularity of track vertical profile[J]. Journal of Sound and Vibration, 2002, 258(1), p: 147-165.

DOI: 10.1006/jsvi.2002.5107

Google Scholar

[4] XiaHe, GuoWei-wei, ZhangNan. Analysis of Resonance Mechanism and Conditions of Train-Bridge System[J] Journal of the China Railway. 2006, 28(5) , P: 53-58.

Google Scholar
