Optimizing Design of Accessories for High-Voltage XPLE Power Cables

Abstract:

This paper describes the optimization design of prefabricated XPLE cable accessories and presents the formula of the design of stress cone. The finite element method for optimizing the design of the electric stress distribution inside the HV power cable joint and adjusting the length and curvature of the stress cone of this termination is discussed. The relationships between dimensions of stress cones structure and the electric field distribution were obtained.

• Periodical: Applied Mechanics and Materials (Volume 441)
• Pages: 189-194
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.441.189
• Online since: December 2013
• Authors: Chao Jie Yang, Jie Chen, Zhi Song Xie, Yi Hui Zeng, Dao Long Wang, Jian Ming Liang, You Ping Fan
• Keywords: Accessories, Finite Element Method (FEM), Stress Cone, XPLE Cable

References

[1] Koo J Y. A design and characterization of condenser cone used for the sealing end of 154 kV of power cable[ C] Conference on Electrical Insulated and Dielectric Phenomena. Arlington, T X, USA: [s. n. ] , 1994: 512-517.

DOI: 10.1109/ceidp.1994.592023

[2] Leijon M, Andersson T. High and dry dryformer power transformer [J]. IEE Review, 2000, 46( 4): 9-15.

[3] TANG Ju, LI Wei, YANG Hao, et al. Ultra high frequency detection and analysis for partial discharge in high voltage cable accessories [J]. High Voltage Engineering, 2009, 35(7): 1571-1577.

[4] GU Jin, WANG Qiao hua, YIN Yi, et al. Design of prefabricated joints for HVDC XLPE power cables [J] . High Volt age Engineering, 2009, 35(12) : 3159-3163.

[5] XU Yuan zhe, WANG Le tian, LIU Xue dong, et al. Design of temperature measurement system f or cable junction based on FBG [ J] . High Voltage Engineering, 2009, 35(12): 2977-2982.

[6] YANG Tiejun, HAN Dong. A few crucial problems about making cross-linked cablejoints of 110kV and above[J]. Heilongjiang Electric power, 2006, 28 (2): 128-130.

[6] Han Xuan, Ma Yong-qi, Research Progress of Prefabricated Rubber Cone Used in High Voltage Cross-linging Cable Termination[J]. High Voltage Engineering, 2007, 40 (4): 12-16.

[7] LI Huachun, ZHANG Luhua, ZHOU Zouchun. Optimizing Design of Stress Controlled Corn by FEM[J]. High Voltage Engineering, 2005, 31(11): 55-57.

[8] WANG Hai-yu, ZHANG Jin-mei, LU Yu-chun, ZENG Shu-jin, LI Shuang-xi, WU Chun-ling. High Voltage Apparatus，47( 10): 106-109.

[9] MA Ziwei, JIA Jiang-bo, ZHA Wei, SUN Fu. Electrical Field Distribution and Adjustment in 10kV XPLE Cable Terminals [J]. High Voltage Apparatus, 2007, 43(4): 304-309.

[10] Blennow H. Electric field reduction due to charge accumulation in a dielectric covered electrode system [J]. IEEE Trans on Dielectrics and Electrical Insulation, 2000, 7( 3) : 340-345.

DOI: 10.1109/94.848912
