Field DC Voltage Withstand Test of Submarine Cable in Hainan Grid Connection Project

Abstract:

500kV Hainan Grid Connection project is the major project connecting Hainan Power Grid to Main China southern power grid. Submarine cable segment is a core part of the whole project. The safety and reliability of the whole project is directly determined by the situation of its main insulation. The submarine cable is affected by a variety of factors in the sectors of manufacturing, transportation and installation. Field voltage withstand test on the submarine cable is of great significance in order to check its insulation condition after installation. In this paper, field DC voltage withstand test of 500kV oil-filled submarine cable is researched. The data obtained in field trials is analyzed to evaluate the main insulation reliability. The results show that the manufacturing quality and the insulation condition installation after laying on site of the submarine cable is reliable, meeting the engineering requirements of safe operation.

• Periodical: Applied Mechanics and Materials (Volume 441)
• Pages: 217-222
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.441.217
• Online since: December 2013
• Authors: Xiao Long Luo, Rui Bie, Liang Zhang, Wei Chen, You Ping Fan
• Keywords: Connection Project, DC Voltage Withstand Test, Field, Insulation Condition, Submarine Cable

References

[1] CHEN Zhong, CAI Ze-xiang. On-site DC Voltage Withstand Test of ±800kV DC Equipment[J]. High Voltage Engineering, 2009, 35(10): 2356-2360.

[2] WANG Guang-yu. 110kV cables with overhead lines for AC voltage test exploration[J]. Science& Technology Information, 2009, 27: 117-118.

[3] XU Shukai1, LIANG Yunyuan. Field Commissioning Test of CNOOC Wenchang VSC-HVDC Transmission System[J]. Southern Power System Technology, 2011, 5(4): 1-4.

[4] WU Du-gui. Review of Acceptance and Preventive Test Technologies of Power Cable Lines[J]. East China Electric Power, 2013, 41(5): 1075-1080.

[5] LIU Wei, XIAO Yong. 220kVCrosslinked long cable AC voltage withstand test on site [J]. High Voltage Engineering, 2008, 34(4): 831-832.

[6] ZHAO Qiang, LIANG Zhi-yong. Analysis of Test on Insulation of High- voltage on Site[J]. Power System Technology, 2006, 30: 291-294.

[7] JIANG Yu-ao, ZHANG Bai-hua, GAO Nai-yu. The research of partial discharge of oil-filled cable paper insulation characteristics[J]. High Voltage Engineering, 2006, 32(7): 54-57.
