Calculation of Power Frequency Electric Field under Overhead Lines with Complex Ground

Abstract:

This paper studied influence of three dimension complex ground on electric field under overhead lines. Surface charge method is discussed and planar triangle surface charge elements are used to represent complex ground. Electric field of overhead lines is analyzed by charge simulation method. Finite straight line charges are used to represent conductors. Then electric field of 220kV double circuit overhead lines over a three dimension small hill is calculated and distribution of electric field 1.5m above the ground is analyzed.

• Periodical: Applied Mechanics and Materials (Volume 441)
• Pages: 212-216
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.441.212
• Online since: December 2013
• Authors: Zhen Guang Liang, Yu Ze Jiang, Di Wen Jiang, Zong Jie Liu
• Keywords: Complex Ground, Electric Field, Overhead Line, Surface Charge Method, Three Dimension

References

[1] A. R. Sinigoj: Electrotech. Rev., vol. 63, no. 2 (1996), p.88.

[2] Yu Jihui, and Zhou Chao: High Voltage Engineering, vol. 32, no. 1 (2006), p.18.

[3] Zhou Hongwei, Zuo Peng, and Zou Jun, et al: Power System Technology, vol. 35, no. 9 (2011), p.164.

[4] M. Trlep, A. Hamler, and M. Jesenik, et al: IEEE Trans. on Magnetics, vol. 45, no. 3 (2009), p.1748.
