Design of Pulse Magnetron Sputtering Deposition Control System Based on Multifunction Controller

Abstract:

A new design technique about pulse magnetron sputtering control system Which bases on multifunction controller and automatic control theory is proposed. This system includes a host PC, a gust multifunctional controller and the local instruments. It controls the process of films deposition automatically and it is also composed of three models corresponding for different operational requests. The characteristic of sputtering deposition films shows the steadily and effectively advantages in this technique.

• Periodical: Applied Mechanics and Materials (Volume 441)
• Pages: 788-791
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.441.788
• Online since: December 2013
• Authors: Yan Liang, Yu Qin, Min Xue Wang, Chang Chun Zhu
• Keywords: Automatic Control, Host PC, Multifuntion Controller, Pulse Magnetron Sputtering

References

[1] R. Childs, .J. Goetz. M. Graf, A. Hubbard, J. Rice and T. Toland, Design. control and operation of the vacuum and gas systems for alcator c-mod, Slassachusetts Institute of Technology Cambridge, MA 02139 , October (1993).

DOI: 10.1109/fusion.1993.518503

[2] L. Wang , Y. Zhang, Q.S. Hu, X.M. Wang, X.D. Zhang, J.S. Hu, Y. Yang, X.M. Gu , Design and construction of vacuum control system on EAST, Fusion Engineering and Design 83 (2008) 295–299, February (2008).

DOI: 10.1016/j.fusengdes.2007.12.001

[3] J. Tang, P. Ladd, D. Williams, J. Crandall, ORNL, Oak Ridge, The design and performance of the integrated spallation neutron source vacuum control system, Proceedings of 2005 Particle Accelerator Conference, May (2005).

DOI: 10.1109/pac.2005.1591597

[4] R. Gavaggio, M. Steffensen and P. M. Strubin, Using models to allow for object oriented programmingof the vacuum control systems", EPAC 1994, London, UK. A. Roth, "Vacuum technology, China Machine Press, October 1980(182-217).

[5] Li Youguang, Wang Jianmin, Sun Yuping, control motor, china machine press, 2009(90-104).
