Controlling Software Design of 2D Scanning Mirror in Infrared Detecting and Tracking System

Abstract:

Firstly, this paper introduced infrared detecting and tracking system (IR D&T System) and several commonly used scanning solutions in IR D&T System briefly. Secondly, it analyzed how 2D scanning mirror works and PID (Proportion, Integration and Differentiation) algorithm. Thirdly, it introduced commands format and controlling method of the 2D scanning mirror used in image-spectrum integrated instrument developed by our group. And then it designed controlling software of the 2D scanning mirror using its secondary development package (SDK) and VC++. The software communicates with 2D scanning mirror through serial port. The MSCOMM serial communication control is used in communication software design. The controlling software is integrated to software of image-spectrum integrated instrument successfully and experiment results verified the correctness of controlling algorithm and engineering usability of the software.

• Periodical: Applied Mechanics and Materials (Volume 441)
• Pages: 805-808
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.441.805
• Online since: December 2013
• Authors: Xiang Yan Liu, Xiao Bing Dai, Xu Dong He
• Keywords: 2D Scanning Mirror, Infrared Detecting, Infrared Tracking, PID, SDK

References

[1] Zhiqiang Hou. A Survey of Visual Tracking, [J] (in Chinese), ACTA AUTOMATICA SINICA, 32(4), 603~617, (2006. 7).

[2] Tianxu Zhang. [Automated Recognition of Imaged Targets] (in Chinese). Wuhan: Hubei Science Technology Press (2005. 4).

[3] Kun Zhao. Research on infrared detection and tracking technology of small target for complex interference environment , [D] (in Chinese), Harbin Engineering University, (2006. 5).

[4] Mingxia Qiao. A long-wave infrared dual-FOV scanning optical system, [J] (in Chinese), Electronics Optics & Control, 20(3), 77~80, (2013. 3).

[5] Zheng Fang, Tianxu Zhang, Yanshan Chen, Xinyu Zhang etc. Dual-band infrared optical system, (in Chinese). Huazhong University of Science and Technology, Chinese patents, ZL200910272921. 2, (Nov. 27, 2009).

[6] Minpu Qiu. Optical design of wide FOV infrared scanning imaging system, [J] (in Chinese), Infrared Technology, 34(11), 648~651, (2012. 11).

[7] Lizhuang Meng. Engineering Thesis double wedge scanning technology in the infrared navigation equipment application , [D] (in Chinese), Xian University of Industry, (2013. 4).

[8] Tianxu Zhang, Zheng Fang, Xiangyan Liu, etc. Method and apparatus for detecting spectral characteristics of multi-band moving objects, 201110430969. 9, PCT/CN2012/070094.

[9] Sheng Li, Yujun Zhang, Minguang Gao, etc. Design of the Moving Mirror Scanning System for a FT-IR Spectrometer, [J] (in Chinese). Infrared Technology, 34 (1) 48 ~ 52 (2012. 1).

[10] Tianxu Zhang, Wei Zhang, Zheng Fang, etc. Multi-modes feature acquisition method of multi targets, (in Chinese). Huazhong University of Science and Technology, Chinese patents, ZL201110260494. 3 (2011).

[11] Fei Wang. DSP-based control system design of anti-rotation servo, [D] (in Chinese), Nanjing University of Science and Technology, (2013. 3).

[12] Shilin Wu. RS485-based computer embroidery machine network, [J] (in Chinese). Mechatronics, 60 ~ 62 (2004. 1).

[13] Jianwei Gong, Guangming Xiong. [Visual C + + / Turbo C serial communication programming practice] [M] (in Chinese). Beijing: Electronic Industry University Press (2004. 10).
