Investigation of Texturing for Mono-Crystalline Silicon without IPA

Abstract:

Isopropyl alcohol (IPA) is widely used as an additive to enhance the alkaline texturing process of mono-crystalline silicon solar cells currently. However, due to its low boiling point and high volatilization, some negative effects are brought into large scale production especially in stability, cost and environment. In this paper, an IPA-free texturing process was studied by using other additive instead of IPA. The influences of concentration of KOH and additive on etching rate, surface morphology and weighted reflectance were investigated. It is found that the additive has an opposite effect on etching rate and pyramid size compared to KOH. The etching rate and average pyramid size decrease with the concentration of additive increased. The best weight reflectance of 10.8% and lowest average pyramid size of 1.1 um were obtained on mono-crystalline silicon surface by an optimized solution of 1.5 wt% KOH and 1.5 wt% additive at 80oC for 20 minutes. Finally, the effects of KOH and IPA-free additive on the texturing process were also discussed in detail.

• Periodical: Applied Mechanics and Materials (Volume 442)
• Pages: 129-133
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.442.129
• Online since: October 2013
• Authors: Su Zhou, Chun Lan Zhou, Jun Jie Zhu, Wen Jing Wang*, Jing Wei Chen
• Keywords: Alkaline Texturing, IPA-Free, Mono-Crystalline Silicon, Solar Cell

References

[1] D. Munoz, P. Carreras, J. Escarre, D. Ibarz, S.M. de Nicolas, C. Voz, J.M. Asensi, J. Bertomeu, Optimization of KOH etching process to obtain textured substrates suitable for heterojunction solar cells fabricated by HWCVD, Thin Solid Films, 517 (2009).

DOI: 10.1016/j.tsf.2009.01.024

[2] H. Park, S. Kwon, J.S. Lee, H.J. Lim, S. Yoon, D. Kim, Improvement on surface texturing of single crystalline silicon for solar cells by saw-damage etching using an acidic solution, Solar Energy Materials and Solar Cells, 93 (2009) 1773-1778.

DOI: 10.1016/j.solmat.2009.06.012

[3] M. Moynihan, C. O'Connor, B. Barr, S. Tiffany, W. Braun, G. Allardyce, J. Rentsch, K. Birmann, In-line and vertical texturing of mono-crystalline solar cells, in: Photovoltaic Specialists Conference (PVSC), 2010 35th IEEE, 2010, pp.001028-001033.

DOI: 10.1109/pvsc.2010.5614629

[4] E.S. Marstein, H.J. Solheim, D.N. Wright, A. Holt, Ieee, Acidic texturing of multicrystalline silicon wafers, in: Conference Record of the Thirty-First IEEE Photovoltaic Specialists Conference - 2005, 2005, pp.1309-1312.

DOI: 10.1109/pvsc.2005.1488381

[5] M. Moreno, D. Daineka, P. Roca i Cabarrocas, Plasma texturing for silicon solar cells: From pyramids to inverted pyramids-like structures, Solar Energy Materials and Solar Cells, 94 (2010) 733-737.

DOI: 10.1016/j.solmat.2009.12.015

[6] P. Papet, O. Nichiporuk, A. Kaminski, Y. Rozier, J. Kraiem, J.F. Lelievre, A. Chaumartin, A. Fave, M. Lemiti, Pyramidal texturing of silicon solar cell with TMAH chemical anisotropic etching, Solar Energy Materials and Solar Cells, 90 (2006).

DOI: 10.1016/j.solmat.2006.03.005

[7] E. Vazsonyi, K. De Clercq, R. Einhaus, E. Van Kerschaver, K. Said, J. Poortmans, J. Szlufcik, J. Nijs, Improved anisotropic etching process for industrial texturing of silicon solar cells, Solar Energy Materials and Solar Cells, 57 (1999) 179-188.

DOI: 10.1016/s0927-0248(98)00180-9

[8] M. Zimmer, K. Birmann, J. Rentsch, Online process control of alkaline texturing baths with near-infrared spectroscopy, Vibrational Spectroscopy, 53 (2010) 269-273.

DOI: 10.1016/j.vibspec.2010.04.005

[9] S.A. Campbell, K. Cooper, L. Dixon, R. Earwaker, S.N. Port, D.J. Schiffrin, Inhibition of pyramid formation in the etching of Si p(100) in aqueous potassium hydroxide-isopropanol Journal of Micromechanics and Microengineering, 5 (1995) 209-218.

DOI: 10.1088/0960-1317/5/3/002

[10] C.R. Yang, P.Y. Chen, Y.C. Chiou, R.T. Lee, Effects of mechanical agitation and surfactant additive on silicon anisotropic etching in alkaline KOH solution, Sensors and Actuators a-Physical, 119 (2005) 263-270.

DOI: 10.1016/j.sna.2004.07.015

[11] K.P. Rola, I. Zubel, Modifying of etching anisotropy of silicon substrates by surface active agents, Central European Journal of Physics, 9 (2011) 410-416.

DOI: 10.2478/s11534-010-0114-9

[12] E. Wefringhaus, A. Helfricht, KOH/surfactant as an alternative to KOH/IPA for texturisation of monocrystalline silicon, Proc. 24th EU PVSEC, Hamburg, Germany, (2009) 1860-1862.

[13] K. Birmann, M. Zimmer, J. Rentsch, Fast Alkaline Etching of Monocrystalline Wafers in KOH/CHX, in: 23rd European PVSEC, (2008).
