A Short Wavelength and Low Loss Thin-Film Transmission Line Employing ML/CPW Composite Structure on Silicon Substrate

Abstract:

In this work, a thin-film transmission line (TFTL) employing microstrip line/coplanar waveguide (ML/CPW) on silicon substrate was proposed, and its RF characteristics were investigated. The TFTL employing ML/CPW composite structure exhibited the wavelength shorter than conventional coplanar waveguide and thin-film microstrip line. Concretely, at 10 GHz, the wavelength of conventional coplanar waveguide and thin film waveguide is 10.35 and 7.83 mm, while the wavelength of the TFTL employing ML/CPW composite structure was 6.26 mm, which was 60.5 % of the conventional coplanar waveguide. The TFTL employing ML/CPW composite structure with a length of λ/8 showed the loss less than 1.12 dB up to 30 GHz, which was lower than conventional coplanar waveguide and thin-film microstrip line. Above results indicates that the TFTL employing ML/CPW composite structure is a promising candidate for application to a miniaturization of RF components on silicon RFIC.

• Periodical: Applied Mechanics and Materials (Volume 442)
• Pages: 138-141
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.442.138
• Online since: October 2013
• Authors: Ki Jun Son, Jang Hyeon Jeong, Sung Jo Han, Young Yun*
• Keywords: Microstrip Line/Coplanar Waveguide (Ml/CPW) Composite Structure, RFIC, Silicon, Thin-Film Impedance Transformer

References

[1] Webster D. R., Ataei G. and Haigh D. G., Low-Distortion MMIC Power Amplifier Using a New Form of Derivative Superposition, IEEE Trans. Microwave Theory Tech., No. 2, Vol. 49, pp.328-332, (2001).

DOI: 10.1109/22.903093

[2] R. E. Collin, Foundation of Microwave Engineering, McGraw-Hill, 2nd edition, (1992).

[3] J. C. Chiu, J. M. Lin, and Y. H. Weang, A Novel Planar Three-Way Power Divider, IEEE Microw. Wireless Compon. Lett., Vol. 16, No. 8, pp.449-451, Aug., (2006).

DOI: 10.1109/lmwc.2006.879489

[4] Li, X., Y. -J. Yang, L. Yang, S. -X. Gong, T. Hong, X. Chen, and Y. –J. Zhang, Novel design of Unequal Wilkinson Power Divider or Dual-Band Operation, Microwave Opt. Technol. Lett., Vol. 52, No. 8, pp.1736-1739, Aug., (2010).

DOI: 10.1002/mop.25296

[5] R Hirota T., Minakawa A. , and M. Muraguchi, Reduced-Size Branch-Line and Rat-Race Hybrids for Uniplanar MMIC's, IEEE Trans. Microwave Theory Tech. Vol. 38, No. 3, pp.270-275, March, (1991).

DOI: 10.1109/22.45344

[6] M. C. Scardelletti, G. E. Ponchak, and T. M. Weller, Miniaturized Wilkinson Power Dividers Utilizing Capacitive Loading, IEEE Microw. WirelessCompon. Lett., Vol. 12, No. 1, pp.6-8, Jan., (2002).

DOI: 10.1109/7260.975717

[7] Y. B. Park, H. N. Joh, S. H. Kim, Y. Yun and I. H. Kang, Highly miniaturized passive components employing novel π-type multiple coupled microstrip lines, Proceeding of 10th Conference On Science and Technology, pp.135-138, 2007, HCM city, Vietnam.

DOI: 10.1109/eumc.2007.4405225

[8] B. C. Wadell, Transmission Line Design Handbook, Artech House, (1991).

[9] F. Schnieder, and W. Heinrich, Model of Thin-Film Microstrip Line for Circuit Design, IEEE Trans. Microwave Theory Tech. Vol. 49, No. 1, pp.104-110, Jan., (2001).

DOI: 10.1109/22.899967

[10] FH. –M. Heilinger, M. Nagel, H. G. Roskos, H. Kurz, F. Schnieder, and W. Heinrich, Thin-Film Microstrip Lines for MM and Sub-MM-wave On-Chip Interconnects, in IEEE MTT-S Int. Microwave Symp. Dig., pp.421-424, (1997).

DOI: 10.1109/mwsym.1997.602823

[11] D. M. Pozar, Microwave Engineering. Reading, MA: Addison-Wesley, (1990).

[12] J. R. Long, Passive Components for silicon RF and MMIC design, IEICE Trans. Electron., vol. E86-C, no. 6, June 2003, pp.1022-1031.
