Study on the Forming Process of the Crossmember in Car Intermediate Floor

Abstract:

Flanging and bending forming processes of the crossmember in car intermediate floor are investigated respectively by using numerical simulation technology. The numerical model of the crossmember was established and its press forming effect was simulated to determine the feasible process parameters affecting its manufacturability. Forming limit diagram and thickness distribution diagram are used to evaluate simulation results of different process schemes. And then optimum values of process parameters for flanging and bending are found, which can reduce the tendencies of wrinkling, springback and crackling during the stamping of the product.

• Periodical: Applied Mechanics and Materials (Volume 442)
• Pages: 593-598
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.442.593
• Online since: October 2013
• Authors: Xue Xia Wang, Peng Chong Guan, Hai Peng Li*, Li Hui Wang, Na Zhang, Xiao Xin Geng, Su Nuan Li
• Keywords: Crossmember, Forming Process, Intermediate Floor, Numerical Simulation Technology

References

[1] H. Wang: Procedia E. Vol. 15 (2011), p.132.

[2] D.C. Ko, S.H. Cha, S.K. Lee, C.J. Lee and B.M. Kim: Mater. Des. Vol. 31 (2010), p.1262.

[3] W. Chen, J.C. Yang and Z.Q. Lin: J. Mater. Process. Technol. Vol. 121 (2002), p.293.

[4] Q. Liu, W.J. Liu, F. Ruan, H.Y. Qiu: J. Mater. Process. Technol. Vol. 187–188 (2007), p.159.

[5] D. R, Va´ncza J, A. R: Comput. Ind. Vol. 56 (2005), p.747.

[6] Lan F, Chen J, Lin J: J. Mater. Process. Technol. Vol. 177 (2006), p.382.

[7] Cho JR, Moon SJ, Moon YH, Kang J: J. Mater. Process. Technol. Vol. 141 (2003), p.109.

[8] Oguz Kayabasi and Bulent Ekici: Mater. Des. Vol. 28 (2007), p.2665.
