Numerical Analysis on the Rapid Starting Period in a Screw-Type Centrifugal Pump

Abstract:

Computational fluid dynamics were used to study the three-dimensional unsteady flows in a closed pipeline system with a screw-type centrifugal pump during rapid starting period. The unsteady Reynold time-averaged Navier-Stokes equations, RNG have been used to solve the unsteady, incompressible, viscous turbulent effects. The sliding mesh technique is proposed to resolve the transient flows caused by the started impeller. Combined with the characteristics of the motor, the screw-type centrifugal pump was started by two different way of linear and exponential acceleration. The automatic update of the rotational speed variation of field around the impeller was realized by FLUENT UDF. The transient variation of the pressure at the pump inlet and outlet, the global performance characteristics and the transient flow evolutions were obtained under different start-up modes. The results show that the rapid starting period presents obvious transient effect; the transient head, power curves changing with time reveal the transient attachment head and additional power part. Compared with the linear mode, the transient flow, shaft power, efficiency tend to a steady state value within a relatively short period in setting start time and maintain a quasi-periodic fluctuations.

• Periodical: Applied Mechanics and Materials (Volumes 444-445)
• Pages: 244-252
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.444-445.244
• Online since: October 2013
• Authors: Xiao Rui Cheng, Ren Nian Li, Wei Li Guo, Nan Zhang, Yang Gao
• Keywords: Centrifugal Pump, Global Performance Characteristics, Screw Type, Starting Period, Transient Flow

References

[1] Tsukamoto H, Ohashi H. Transient Characteristics of a Centrifugal Pump During Starting Period [J]. ASME Journal of Fluid Engineering, 1982, 104(1): 6-13.

DOI: 10.1115/1.3240859

[2] Li Zhifeng. The numerical simulation and experimental research of the transient flow in centrifugal pump start-up process [D]. Hangzhou: Zhejiang university, (2009).

[3] Lefebvre P J, Barker W P. Centrifugal Pump Performance During Transient Operation [J]. ASME Journal of Fluid Engineering, 1995, 117(2): 123-128.

DOI: 10.1115/1.2816801

[4] Wu Dazhuan, Jiao Lei, Wang Leqin. The experimental study on the transient hydraulic performance in centrifugal pump under different start-up acceleration[J]. Journal of engineering thermal physics, 2008, 29(1): 62-64.

[5] Homsby, Craig. CFD-Driving Pump Design Forward [J]. World Pumps, 2002, 18-22.

[6] Tsukamoto H, et al. Transient Characteristics of a Centrifugal Pump During Stopping Period [J]. ASME Journal of Fluid Engineering., 1986, 392-399.

DOI: 10.1115/1.3242594

[7] P Thanapandi, R. Prasad. Centrifugal Pump Transient Characteristics and Analysis Using the Method of Characteristics [J]. International Journal of Mechanical Sciences, 1995, 37(1): 77-89.

DOI: 10.1016/0020-7403(95)93054-a

[8] Wang Leiqin, Li Zhifeng, Dai Weiping, et al. The two-dimensional numerical simulation of internal transient flow in centrifugal pump start-up process[J]. Journal of engineering thermal physics, 2008, 29(7): 1319-1322.

[9] Wang Leqin, Wu Dazhuan, et al. The vane pump start-up characteristic simulation based on bond graph method [J]. Journal of engineering thermal physics, 2004, 25(3): 417-420.

[10] Zhifeng Li, Peng Wu, Dazhuan Wu. Experimental and numerical study of transient flow in a centrifugal pump during startup [J]. Journal of Mechanical Science and Technology, 2011, 25 (3): 749~757.

DOI: 10.1007/s12206-011-0107-7

[11] Guo Xianjun, Chen Hongxun, Zhu Bin. Numerical simulation of centrifugal pump start-up process[J]. Journal of Shanghai university (JCR-SCI), 2012, 18(3): 288~292.

[12] Zhang Yuliang, Zhu Zuchao, Ling Huichao, et al. Calculation of the additional theoretical lift in the start-up process of centrifugal pump[J]. Mechanics quarterly, 2012, 33(3): 456-460.

[13] Li Rennian, Han Wei, Li Qifei, et al. Prediction and Experiment about the Effect of the Clearance on Performance of Screw Centrifugal Pump [J], Transaction of the Chinese Society of Agricultural Engineering, 2007, 38(6): 79-81.

[14] Kitano Majidi. Numerical Study of Unsteady Flow in a Centrifugal Pump [J]. Journal of Turbormachinery, 2005, 127(4): 363-371.

DOI: 10.1115/1.1776587
