Numerical Simulation on Backwater Downstream of Aerators in Spillway Tunnel with Ultra-Low Frounde Number Flow

Abstract:

The backtracking of flow occurs easily in cavity of aeration step in spillway tunnel with a gentle bottom slope and ultra-low Frounde number, and this influences the intake of air, so combined with the spillway tunnel of Chang heba Hydropower Station, four bodily form of aeration steps are chosen to be studied by both numerical simulation and model test based on κ-ε turbulence model, they are continuous aeration step, U-type aeration step + local steep slope, continuous aeration step + circular arc type steep slope and continuous aeration step + ogee curve steep slope, the results show that, the downstream bottom slope of aeration step with suitable ogee curve or circular arcs can efficiently inhibit the backtracking of flow in continuous aeration step, and can efficiently eliminate hydrops in cavity and in the same time can improve the efficiency of aeration. Usually, the results of bottom slope with an ogee curve are better than that with a circular arc.

• Periodical: Applied Mechanics and Materials (Volumes 444-445)
• Pages: 539-543
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.444-445.539
• Online since: October 2013
• Authors: Li Qiang Chen, Jun Xing Wang, Yu Ting Chen
• Keywords: Arc Bottom Slope, Hydrops in Cavity, Numerical Simulation, Ogee Curve, Ultra-Low Frounde

References

[1] YANG Yongsen, YANG Yongquan. The hydraulic and aeration characteristics of low Froude number flow over a step aerator[J], journal of hydraulic engineering(2), 2000, (2) : 272311.

[2] SUN Shuang-ke, YANG Jia-wei, LIU Hai-tao. Optimistic study on the layout of aeration facilities under mild gradient[J], Technology on water resources and hydropower, 2004, 35 (11) : 262291.

[3] WANG Hai - yun, DAI Guang -qing, YANG Qing. Experimental study on V-type aerator for spillway tunnel with inlet raised[J], journal of hydraulic engineering, 2005, 36(11), 1371-1374.

[4] ZHANG Liheng, XU Weilin. Experimental Investigation on the Backwater behind Aeration Facility[J], Science Technol ogy and Engineering, 2006, 6(15).

[5] Qi Li-jian, LIAO Sheng-hua, LI Gui-ji. Numerical simulation on backwater downstream of aerators in spillway with low froude number flow[J], journal of hydraulic engineering, 2007, 38(7).

[6] YANG Hongxuan, XU Yimin, ZHAO Wei. Numerical simulation on 2 _ D turbulent flow of backwater in cavity of jet flow from chute aerator[J], Technology on water resources and hydropower, 2011, 42(10).

[7] XU Yimin, WANG Wei, XU Weilin. Calculate on backwater downstream of aerators jet flow[J], Progress in Natural Science, 2008, 18(5).

[8] XU Yimin, ZHAO Wei, YANG Hongxuan. Influences of ramp size, Froude number and bottom cavity pressure on the cavity backwater of an aerator[J], Journal of Hydroelectric Engineering, 2010, 29(4).
