A New Classification Algorithm of MPSK Signals Based on Phase Distribution

Abstract:

Based on the phase distribution which is defined in this paper, a new classification algorithm of M-ary phase shift keying (PSK) signals is proposed. To classify the modulation type of the M-ary PSK signal, the phase distribution of the unclassified signal is calculated firstly, and then the characters of the signal modulation are extracted by computing the FFT of the phase distribution. Moreover, the method is improved in this paper that it is extended to MPSK baseband signals with frequency offset, and the calculation complexity is reduced. Simulation result shows that the accuracy rate of the classification of BPSK, QPSK and 8PSK signals can reach 98.5% when the symbol length is 500, SNR is 3dB, and 16PSK signals can also be well classified when the SNR improves to 9dB.

• Periodical: Applied Mechanics and Materials (Volumes 446-447)
• Pages: 1028-1033
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.446-447.1028
• Online since: November 2013
• Authors: Jian Fei Xu*, Fu Ping Wang, Zan Ji Wang
• Keywords: Modulation Classification, MPSK, Phase Distribution

References

[1] B. F. Beidas and C. L. Weber, Higher-order correlation-based approach to modulation classification of digitally frequency-modulated signals, IEEE Journal on Selected Aeas in Communications, vol. 13, no. 1, Jan. 1995, pp.89-101.

DOI: 10.1109/49.363142

[2] D. Boiteau and L. Martret, A general maximum likelihood framework for modulation classification, IEEE International Conference on Acoustics，Speech and Signal Processing, vol. 4, May. 1998, pp.2165-2168.

DOI: 10.1109/icassp.1998.681575

[3] W. Wei and J. M Mendel, Maximum-likelihood classification for digital amplitude-phase modulation, IEEE Trans. Communications, vol. 48, no. 2, Feb. 2000, pp.189-193.

DOI: 10.1109/26.823550

[4] A. K. Nandi and E. E. Azzouz, Algorithms for automatic modulation recognition of communication signals, IEEE Transactions on Communication, vol. 46, no. 4, Apr. 1998, pp.431-436.

DOI: 10.1109/26.664294

[5] Fan Hai-bo, Yang Zhi-jun and Cao Zhi-gang, Automatic recognition for common used modulations in satellite communication, Journal of China Iinstitute of Communications, vol. 25, no. 1, Jan. 2004, pp.140-149.

[6] A. Swami and B. M．Sadler, Hierarchical digital modulation classification using cumulants, IEEE Transactions on Communications, vol. 48, no. 3, Mar. 2000, pp.416-429.

DOI: 10.1109/26.837045

[7] B. G．Mobasseri, Digital modulation classification using constellation shape, Signal Processing 80, 2000, pp.251-277.

DOI: 10.1016/s0165-1684(99)00127-9

[8] Heinrich Meyr, Marc Moeneclaey and Stefan A. Fechtel, Digital Communication Receivers: Synchronization, Channel Estimation, and Signal Processing, John Wiley & Sons, Inc, (1998).

DOI: 10.1002/0471200573
