Energy Absorption of Hybrid Composite Tubes under Axial Compression

Abstract:

The effect of specific absorbed energy on pultruded profile and thin-walled aluminum composite square cross-section tubes were studied via experimentally. The type of strand mat E-glass reinforced polyester resin was conducted in this study. The specimens of square pultruded and thin-walled wrapped strand mat E-glass composite were compressed under quasi-static of obliquely loadings from the top moving plat platen. For each specimen of composite tubes, triggering mechanism was applied on frontal end top of the tube to obtain the progressive failure throughout the crash event. The pultruded profile tube wall-thicknesses of 2.1 mm and thin-walled aluminum 1.9 mm thickness wrapped 3 layer woven fabric were examined, and the effects of crushing behaviors and failure modes were discussed. Results showed that the tubes energy absorption capability was affected significantly by different type of composite made in term of internal energy.

You might also be interested in these eBooks

Advanced Research in Material Science and Mechanical Engineering

View Preview

Info:

Periodical:

Applied Mechanics and Materials (Volumes 446-447)

Pages:

109-112

DOI:

https://doi.org/10.4028/www.scientific.net/AMM.446-447.109

Citation:

Cite this paper

Online since:

November 2013

Authors:

A. Othman, A.A. Arifin, S. Abdullah, A.K. Ariffin, N.A.N. Mohamed

Keywords:

Composite Tube, Energy Absorption, Off-Axis Load, Thin-Walled Aluminium

Export:

RIS, BibTeX

Price:

Permissions CCC:

Request Permissions

Permissions PLS:

Request Permissions

Сopyright:

Citation:

References

[1] Mamalis, A.G., Manolakos, D.E., Ioannidis, M.B., Kostazos, P.K., Papapostolou, D.P.: Axial collapse of hybrid square sandwich composite tubular components with corrugated core: numerical modelling. Compos. Struct. 58(4), 571–582 (2002).

DOI: 10.1016/s0263-8223(02)00166-6

Google Scholar

[2] A. A. Arifin, A. B. Sulong, Quasi-static energy absorption of pultruded composite tubes E-glass/polyester under oblique loading with different cross-section. Advanced Materials Research. 2012; 341-342: 843-847.

DOI: 10.4028/www.scientific.net/amr.341-342.843

Google Scholar

[3] A. Othman, S. Abdullah, A. K. Ariffin, N. A. N. Mohamed, On the Crushing Behavior of Foam-Filled Composite Tubes under Compressive Loading. Advanced Materials Research. 2013. Vol. 337 pp: 479-488.

DOI: 10.4028/www.scientific.net/amr.626.1038

Google Scholar

[4] S. Abdullah, A. A. Arifin, A. Othman, A. K. Ariffin, N. A. N. Mohamed, Crushing Behavior of Hybrid Foam-Filled Pultruded Composite under Quasi-Static Oblique Loading. Advanced Materials Research. 2013. Vol. 664 pp.649-653.

DOI: 10.4028/www.scientific.net/amr.664.649

Google Scholar
