Improvement Shifting Control of Continuously Variable Transmission (CVT) by Using PID, Pole Placement and LQG

Abstract:

In this paper, the CVT shifting control system based on vehicle operating conditions is modeled and simulated using MATLAB/SIMULINK. The modeling stage begins with the derivation of required mathematical model to illustrate the CVT shifting control system. Then, Linear Quadratic Gaussian (LQG), Proportional- Integrated-Derivative (PID) and Pole Placement are applied for controlling the shifting speed ratio of the modeled CVT shifting system. Simulation results of shifting controllers are presented in time domain and the results obtained with LQG are compared with the results of PID and Pole placement technique. Finally, the performances of shifting speed ratio controller systems are analyzed in order to choose which control method offers the better performance with respect to the desired speed ratio. According to simulation results, the LQG controller delivers better performance than PID and Pole Placement controller.

• Periodical: Applied Mechanics and Materials (Volumes 446-447)
• Pages: 1165-1170
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.446-447.1165
• Online since: November 2013
• Authors: Shu Yuan Ma, Bdran Sameh, Saifullah Samo, Aymn Bary
• Keywords: CVT, LQG, PID, Pole Placement, Simulation

References

[1] Hoon Yeo, Donghyun Kim, Sungho Hwang, Hyunsoo Kim, Regenerative Braking algorithm for a HEV with CVT Ratio Control During Deceleration, he art of writing a scientific article, J. Sci. Commun. 163 (2000) 51-59.

[2] Roland Molle, Control and Operating Behavior of Continuously Variable Chain Transmission nsoo Kim, he art of writing a scientific article, J. Sci. Commun. 163 (2000) 51-59.

[3] Lei Zhang , Huiwu Li, Guoning Li, The Control Theory and Implementation Method of Clamping Force, 2009 International confernce on Artificial Intelligence and Computational Intelligence.

DOI: 10.1109/aici.2009.408

[4] Michiel Pesgens, Bas Vroemen, Bart Stouten, Frans Veldpaus and Maarten Steinbuch. Control of a Hydraulically Actuated Continuously Variable Transmission. Vehicle System Dynamics, May 2006, Vol. 44, No. 5, p.387–406.

DOI: 10.1080/00423110500244088

[5] Kai Wang, Xianglei Zhang, Yanhui Zhong, Research on the Ratio Control of Metal Belt CVT, International Conference on Electronic & Mechanical Engineering and Information Technology, (2011).

DOI: 10.1109/emeit.2011.6023056

[6] Ogata K. Modern control engineering. 4thed. New Jersey. Prentice Hall Publication, (2001).

[7] Information on http: /www. weld. labs. gov. cn.

[8] S. Skogestad and I. Postlethwaite. Multivariable feedback control . Wiley, (1996).

[9] Dingyu Xue, Yang Quan Chen, Derek P. Atherton, Linear Feedback Control analysis and design with MATLAB , the Society for Industrial and Applied Mathematics, (2007).
