The Design of Damping Block in the Tire Tread Extrusion Die

Abstract:

It is one of the keys that determining reasonable damping block geometry in the process of designing the extrusion dies. In this paper, the finite element software POLYFLOW was used to simulate the flow process of tread rubber in the head channel. In addition, the orthogonal experiment method was adopted for the optimum design of the damping block in the head channel. After optimum design, the flow velocity of rubber melt becomes more uniform in the full width at the head outlet. Consequently, the warping deformation of the rubber, which flow through the head channel, is also significantly reduced.

• Periodical: Applied Mechanics and Materials (Volumes 446-447)
• Pages: 356-359
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.446-447.356
• Online since: November 2013
• Authors: Peng Fei Wen*, Ping Ping Xu, Kai Ding
• Keywords: Damping Block, Design, Extrusion Die, Tire Tread

References

[1] Xie Delun: Rubber extrusion (Chemical Industry Press, China, 2005).

[2] Cormenzana J, Ledda A, Laso M, et al: J. Rheol. Vol. 45 (2001), p.237.

[3] Gevgifli H, Kalyon DM: J. Rheol. , Vol. 45 (2001), p.467.

[4] Liang Jizhao: Polymer Experimenting Vol. 22(2003), p.497.

[5] Rutgers RPG, Mackley MR: J. Non-Newton. Fluid Mech. Vol. 98(2001), p.185.

[6] Carneiroa OS et al: Journal of Materials Processing Technology Vol. 114 (2001), p.75.

[7] Wen Jialing, Wen Pengfei: Journal of Wuhan University of Technology-Mater. Sci. Ed. Vol. 20 (2005), p.86.
