The Structural Design and Analysis for the Box-Wrench’s Hot Extrusion Die

Abstract:

Box-Wrench is a tool widely used in industry and especially suitable for screwing the bolt and the nut in the place where the space is very narrow and dent. In this paper, a process of hot extrusion box-wrench was presented. The structure of hot extrusion die and its working process were discussed. The feasibility of the process and the workability of the die were analyzed with Finite Element Analysis. The external diameter and the length of the box-wrench are designed according to the equipment's shape and size, the box-wrench's structure should be relatively flexible. How to manufacture the box-wrench in high efficiency and with high quality is the most important question of the box-wrench producing.

• Periodical: Applied Mechanics and Materials (Volumes 446-447)
• Pages: 655-659
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.446-447.655
• Online since: November 2013
• Authors: Xin Ping Hu, Wei Long Diao
• Keywords: Box-Wrench, Die, Hot-Extrusion, Structure Design

References

[1] SS Akhtar and AFM Arif. Fatigue failure of extrusion dies: effect of process parameters and design features on die life [J]. Failure Analyse and Prevent, 2010(10): 38-49.

DOI: 10.1007/s11668-009-9304-4

[2] Cunsheng Zhang, Guoqun Zhao, Hao Chen, et al. Numerical simulation and metal flow analysis of hot extrusion process for a complex hollow aluminum profile [J]. International Journal of Advanced Manufacturing Technology, 2012(60): 101-110.

DOI: 10.1007/s00170-011-3609-7

[3] S Syahrullai, CSN Azwadi, YM Naji, et al. The influences of the die half angle of taper die during cold extrusion process [J]. Arabian Journal for Science and Engineering, 2013(38): 1201-1207.

DOI: 10.1007/s13369-012-0531-8

[4] JH Yoon, NK Lee, DY Yang, et al. Treatment of contact traction at the die workpiece interface for the elastic analysis of die deformation[J]. International Journal of Mechanical Sciences, 1992(9): 689-702.

DOI: 10.1016/0020-7403(92)90002-x

[5] HT Yeo, Y Choi and K D Hur, et al. Analysis and design of the prestressed cold extrusion die [J]. Interation Journal of Advanced Manufacturing Technology, 2001(18): 54-61.

DOI: 10.1007/s001700170094

[6] Yang B, Zhang WG, Li SH, et al. Analysis and finite element simulation of the tube bulge hydroforming process [J]. International Journal of Advanced Manufacturing Technology, 2006 (29): 453-458.

DOI: 10.1007/s00170-005-2548-6
