Welding Performance of a Homemade Friction Stir Welding Tool

Abstract:

Homemade Friction Stir Welding (FSW) Tool utilizing conventional milling machine has been developed. The FSW tool made from mild steel was designed and fabricated. Experimental investigation of FSW process of the Aluminum alloy specimens to observe its mechanical performances was performed. To evaluate its performance, hardness test, tensile test as well as visual inspections of the welding result were performed. Hardness number in the welding region was measured about 40-60% lower than the base metal, and heat affected zone region. The tensile test result varies with maximum 100 MPa. The imperfection of final form of metal due to the stirring mechanism was inspected. The presence of void/crack at cross-section of the welded specimen was observed. It was found that by applying suitable configuration, the use of mild steel as the FSW tool was reasonable for performing FSW process. It was concluded that, using a relatively low cost FSW tool, a quite satisfactory result of welding performance was achieved.

• Periodical: Applied Mechanics and Materials (Volumes 446-447)
• Pages: 660-664
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.446-447.660
• Online since: November 2013
• Authors: Irfan Hilmy, Erry Yulian T. Adesta
• Keywords: Friction Stir Welding (FSW), Mechanical Testing, Welding Performance

References

[1] K. Hemanth Vepakomma, Three Dimensional Thermal Modeling Of Friction Stir Processing, Master Thesis, The Florida State University College Of Engineering, (2006).

[2] Jerry C. Wong, The Correspondence between Experimental Data and Compute Simulation of Friction Stir Welding (FSW), Master Thesis, College of Engineering and Mineral Resources at West Virginia University, (2008).

[3] Calvin Blignault, Design, Development and Analysis of the Friction Stir Welding Process, Master Theses, Faculty: Electrical, Industrial & Mechanical Engineering Port Elizabeth Technikon, (2002).

[4] Thomas, W.M., Threadgill P.L., and Nicholas, E.D., Friction stir welding of steel: Part one, http: /steel. keytometals. com/default. aspx?ID=CheckArticle&NM=219.

[5] Thomas W.M., Nicholas E.D., Smith S.D., Friction Stir Welding-Tool Developments, Aluminum Proceedings 2001, TMS (2001).

[6] Thomas W.M., Friction stir welding and related friction process characteristics, International Conference 7th, April 1998, Joints in Aluminum: Inalco'98, (1999).
