Dynamic Adjusting Mechanism of Counterbalance in Beam-Pumping Unit and its Kinetic Analysis

Abstract:

The purpose of conventional counterbalance mechanism featuring a fixed counterbalance torque is to balance the nonuniformity of polished rod load. Therefore, it cannot satisfy the demand of polish rod load which changes with well-condition and then leads to increase of power cost for decreasing quality of balance. This paper presents a new dynamic adjusting mechanism of counterbalance in beam-pumping unit that can adjust the counterbalance torque automatically without stopping the unit according to the new balance parameters derived by analyzing the variation of well-condition and increase productivity at the same time. A data comparison based on the corresponding kinetic model of transmission mechanism is also discussed.

• Periodical: Applied Mechanics and Materials (Volume 455)
• Pages: 274-278
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.455.274
• Online since: November 2013
• Authors: Xiao Qing Kang*, Tao Ren, Wen Tao Qu
• Keywords: Beam-Pumping Unit, Counterbalance, Dynamic Adjustment, Kinetic Analysis

References

[1] J.J. Kilgore, H.A. Tripp and C.L. Hunt Jr.: Society of Petroleum Engineers 22788(1991), p.291.

[2] Wang Fengshan, Liu He and Zhou Fangfu: Society of Petroleum Engineers 124646(2009), p.1.

[3] J. N. McCoy, W. A. Drake: Journal of Canadian Petroleum Technology Vol. 38 (1999), p.5.

[4] Gao Shiyong, Luo Xiaohui, Niu Zehao and Li Anzhi: Science &Technology Information Vol. 35 (2010), p.503.

[5] D. Su, X. Liu, W. Lu, J. Ding, S. Liu, X. Qiu, Y. Ren: China Petroleum Machinery Vol. 29 (2001), P. 49.

[6] B. Wan: Oil Production Equipment Design and Calculation, First edition (Petroleum Industry Press, Beijing 1988).
