Research on the Cooperative Control Method for Trajectory Tracking of Automatic Guided Vehicle Based on Dynamic Position/Force

Abstract:

AbstractConsidering the influence of the dynamic characteristic of automatic guided vehicle (AGV) on trajectory tracking controlling, double closed loop control structure is proposed to realize the position/force cooperative control. The outer loop controlling uses backstepping to design corresponding position controller for kinematics model of AGV, while the inner control uses the integral sliding mode controlling. Self-adaptive controlling law is used to estimate the uncertain external interference in the driving force controller and stability of AGV trajectories tracking proof is proposed. In order to make the system achieve better control performance and prevent the occurrence of severe wobble, the hyperbolic tangent function in the control law of sliding mode control replaces the sign function to ensure a continuously smooth control input and states of the system. In the Matlab/simulink environment, tracking a given splayed trajectory generated by the S function to verify the double closed loop control structure and the effectiveness of the control algorithm proposed in this paper.

• Periodical: Applied Mechanics and Materials (Volumes 457-458)
• Pages: 1298-1302
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.457-458.1298
• Online since: October 2013
• Authors: Xuan Zuo Liu, Qiao Yun Yan, Fei Yun Tang
• Keywords: Backstepping, Double Closed Loop Control Structure, Position/Force Cooperative Control, Sliding-Mode Control

References

[1] M. Yue, Y. Zhang, F.Y. Tang. Path following control of a two-wheeled surveillance vehicle based on sliding mode technology[J]. Transactions of the Institute of Measurement and Control, (2012).

DOI: 10.1177/0142331212441488

[2] L. Jiang, M. Deng, A. Inoue. Obstacle avoidance and motion control of a two wheeled mobile robot using SVR technique[J]. International Journal of Innovative Computing, Information and Control, 2009, 2 (5): 253-262.

DOI: 10.1109/icicic.2007.553

[3] M. Yue, W. Sun, P. Hu. Sliding Mode Robust Controlfor Two-wheeled Mobile Robot With Lower Centerof Gravity[J]. International Journal of Innovative Computing, Information and Control, 2011, 7 (2): 637-646.

[4] H.K. Khalil, J. Grizzle, Nonlinear systems[M]. Upper Saddle River, NJ: Prentice-Hall: Macmillan Publishing Company New York, (1992).
