Design of Embedded Controller with Flexible Programming for Industrial Robot

Abstract:

This paper presents an embedded controller of low cost and high performance for industrial robot. The ARM microprocessor is chosen as the main controller for the processor. Based on the 7-segment cubic spline interpolation algorithm, a real-time control for the robot is implemented. This proposed trajectory method can perfectly generates speed S-curve shape for a start-stop process of the robot. In this article a programming language, G-code, is developped for the robots motion control by using the editing interface we designed specially on PC platform. With all the features for 2-4 degree of freedom robot application, the editing interface has been developed for editing and compiling G-code, which can be downloaded into the microprocessor with the custom communication protocol through communication interface. The programming method of the G-code language is easy to learn and use for the non-professional users. The paper describes the design and implementation in detail for the controller, which was validated on our designed SCARA robot, and it worked reliably.

• Periodical: Applied Mechanics and Materials (Volumes 457-458)
• Pages: 1390-1395
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.457-458.1390
• Online since: October 2013
• Authors: Zheng Dong Wang, Kai He, Hai Tao Fang, Ruxu Du
• Keywords: Cubic Spline Interpolation, Embedded Controller, G-Code, Robot, Trajectory Planning

References

[1] TOMAS LOZANO-PEREZ. Robot Programming. Proceedings of the IEEE. July 1983, VOL. 71, NO. 7.

[2] Frank S. Cheng. Programming Advanced Control Functions for Enhanced Intelligence of Industrial Robots. Proceedings of the 8th World Congress on Intelligent Control and Automation, Jinan, China. July 6-9 (2010).

DOI: 10.1109/wcica.2010.5554085

[3] Heping Chen, Weihua Sheng. Transformative Industrial Robot Programming in Surface Manufacturing. 2011 IEEE International Conference on Robotics and Automation, Shanghai, China. May 9-13, (2011).

DOI: 10.1109/icra.2011.5979570

[4] Adelhard Beni Rehiara , Wim Smit. Controller Design of a Modeled Adept Three Robot Arm. Proceedings of the 2010 International Conference on Modelling, Identification and Control, Okayama, Japan. July 17-19, (2010).

[5] Guan Xiaoqing, Wang Jidong. Trajectory planning theory and method of industrial robot. Computer Research and Development (ICCRD), 2011 3rd International Conference on (Volume: 2 ). 11-13 March (2011).

DOI: 10.1109/iccrd.2011.5764146

[6] Haosong Yue, Weihai Chen, Wenjie Chen, Xingming Wu. Spline-Interpolation based PVT Algorithm and Application in a Bionic Cockroach Robot. 2010 11th Int. Conf. Control, Automation, Robotics and Vision, Singapore. 7-10th December (2010).

DOI: 10.1109/icarcv.2010.5707324

[7] Ningping Sun, Toru Ayabe, Takahiro Nishizaki. Efficient Spline Interpolation CurveModeling. Intelligent Information Hiding and Multimedia Signal Processing, 2007. 26-28 Nov. (2007).

DOI: 10.1109/iihmsp.2007.4457653

[8] STMicroelectronics. STM32F103xx Reference manual. www. st. com. October (2011).
