Studies on Sprinklers Arrangement in Sprinkler Systems

Abstract:

To improve the fire suppressing efficiency and reliability of the sprinkler systems, in this paper we analysis and discuss a problem about sprinklers arrangement. Use the water distribution curve of ZST-15 and the MATLAB to accomplish a 3D surface fitting among radius of protection, working pressure and mounting height as well as get a function expression about them. After that, aiming at the problems happened in engineering practice, we propose a method of determine the sprinklers arrangement distance and their mounting height, in addition give suggestions about choosing fire pools and work out the flow rate of sprinkler systems through calculation as well.

• Periodical: Applied Mechanics and Materials (Volumes 457-458)
• Pages: 1686-1690
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.457-458.1686
• Online since: October 2013
• Authors: Fan Lin Cui, Fang Qu, Yong Yi Cui, Lei Mai
• Keywords: Fire Pool, Sprinkler Systems, Sprinklers Arrangement, Water Spray Intensity

References

[1] Du Kun: Study on Optimizing the Layout of Nozzle in Sprinkler System, Master degree thesis in Chongqing University, China (2010) (In Chinese).

[2] Deng Ke-yang: The numerical simulation of the spatial distribution of water spray intensity for ZST-15 sprinklers, journal of China water & wastewater, supplement of Vol. 33 (2007) (In Chinese).

[3] XU Xiao-ling, YAO Bin, WANG Han-jie and LI Juan: Water density probability distribution and fire control capability of sprinkler system, journal of FIRE SAFETY SCIENCE, Vol. 18, No. 3 (2009) (In Chinese).

[4] Huang Zi-qin, Wu Jiu-jiu: Proper setting of sprayer in auto-spraying fire-extinguishing system, journal of China water & wastewater engineering, Vol. 15, No. 7 (1999) (In Chinese).

[5] Wang Jia-hai: Discussion on Design of the sprinkler systems, journal of China water & wastewater, Vol. 20 (2004) (In Chinese).

[6] Yang Qi: On the maximum space of nozzles in automatic sprinkling system, journal of China water & wastewater, Vol. 23, No. 10 (1997) (In Chinese).

[7] Su Wen-long: Studies on the Building Fire Automatic Sprinkler System and Hydraulic Calculation, Master degree thesis in Hefei University of Technology, China (2007) (In Chinese).

[8] CAI Gao-tang, WANG Feng: On Standard Limited Value of Sprinkler Head Distance About Automatic Spraying Fire-Extiguishing System, journal of Nanchang College of Water Conservancy and Hydroelectric Power, Vol. 19, No. 1(2000) (In Chinese).

[9] Huang Xiao-jia, Jiang Wen-yuan: Handbook of water-based fire protection systems, [M] China architecture & building press (2006). (In Chinese).

[10] China institute of building standard design & research: Sprinkler and water spray extinguishing facilities installation, 04S206, [M] China planning press (2008) (In Chinese).

[11] Code of design for sprinkler systems, [S] GB 50084-2001 (2005) (In Chinese).
