Performance Analyses and Experimental Verification for the Clamping Mechanism of Die Casting Machine

Abstract:

The research object of this paper is double-toggle clamping mechanism of DC3500 die casting. The theoretical formulas of stroke ratio and force amplification are proposed and the prototype model is established in ADAMS to generate kinematic and mechanical curves. Moreover, experimental values are used to verify the validity of the theoretical formulas and simulation model, and the causes of experimental error are gaven. Thus, the theoretical model can be adopted directly for the design of larger double-toggle clamping mechanism to simplify the design cycle.

• Periodical: Applied Mechanics and Materials (Volume 464)
• Pages: 116-122
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.464.116
• Online since: November 2013
• Authors: Guo Yin Wu*, Wen Cheng Tang, Shui Ping Wan
• Keywords: Die Casting, Double-Toggle Clamping Mechanism, Experimental Verification, Force Amplification, Stroke Ratio

References

[1] Yu Yanjiang, Cai Jianping. The research on the parameters of the jojnt-double clamping unit of die-casting machine[J]. Machinery Design & Manufacture, 2007(12): 82-83.

[2] Liao Xuqin. Simulation and optimization design for joint-double clamping mechanism of a horizontal squeeze casting equipment[J]. Modern Manufacturing Engineering, 2012(1): 48-51.

[3] Ming-Shyan Huang, Tsung-Yen Lin, Rong-Fong Fung. Key design parameters and optimal design of a five-point double-toggle clamping mechanism[J]. Applied Mathematical Modelling, 2011, 35(9): 4304-4320.

DOI: 10.1016/j.apm.2011.03.001

[4] Xiong Wanchun, Jin Zhiming, et al. Movement and Forces Characteristics of Double-toggle Clamping Mechanism in Die Casting Machine[J]. Special Casting & Nonferrous Alloys, 2008, 28(6): 445-447.

[5] Lin W Y, Wang S S. Dimensional synthesis of a five-point double-toggle mould clamping mechanism using a genetic algorithm-differential evolution hybrid algorithm[J]. Proceedings of the Institution of Mechanical Engineers Part C-journal of Mechanical Engineering Science, 2010, 224(C6): 1305-1313.

DOI: 10.1243/09544062jmes1951

[6] Liu Tao. Structural Optimization Design of DC280 Die Casting Machine[D]: Nanjing. Southeast University, 2011, 6.

[7] Lin WY, Shen CL, Hsiao KM. A case study of the five-point double-toggle mould clamping mechanism[J]. Proceedings of the Institution of Mechanical Engineers Part C-journal of Mechanical Engineering Science, 2006, 220(4): 527-535.

DOI: 10.1243/09544062jmes216

[8] Zhao Wuyun, Liu Yanyan, Wu Jianmin, et al. Foundation and Application Examples of ADAMS Tutorial[M]. Beijing: Tsinghua University Press, (2012).
