Implementation of ESD Protection for Output Driver ICs with SCR Circuits Techniques

Abstract:

In this paper, an output driver which drove a large current in DC brushless fan ICs was taken for the HBM ESD stress. The protection circuits of this IC were also designed to improve ESD robustness by various layout parameters and structures. From the ESD testing results, it was found that the positive Pad-to-VSS (PS) zapping mode was weakest for the output driver of DC brushless fan ICs during ESD stress. Eventually, protection circuits with a complementary low-voltage-triggered SCR (LVTSCR) were used to protect the whole-chip ESD stress. After a systematic improvement, an SCR structure of adding protection circuits can effectively protect the whole-chip ESD reliability, as compared with the original DUT; the ESD failure threshold (V_ESD) of PS mode is increased 314% in a best structure when an LVTSCR with the drain-tap S space is 4μm.

• Periodical: Applied Mechanics and Materials (Volume 464)
• Pages: 139-144
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.464.139
• Online since: November 2013
• Authors: Shen Li Chen*, Der Ann Fran
• Keywords: Drain-Contact to Poly-Gate Edge (DCG), Electrostatic Discharge (ESD), ESD Failure Threshold (V_ESD), Human-Body Model (HBM), Latch-Up (LU), Low-Voltage-Triggered SCR (LVTSCR), Positive Pad-To-VSS (PS) Mode

References

[1] Yingyan Linm, Xuecheng Zou, Zhaoxiao Zheng, Wenjie Huo, Xiaofei Chen, Wenjing Kang: 12th International Symposium on Integrated Circuits (2009), p.280.

[2] Guannan Wang, Wengao Lu, Ran Fang, Li You, Yacong Zhang, Zhongjian Chen, Lijiu Ji: International Conference of Electron Devices and Solid-State Circuits (2011), p.1.

DOI: 10.1109/edssc.2013.6628094

[3] Hongmei Yang, Hua Gua, Xin Yu, Qingqing Zhang: 2nd International Conference on, Consumer Electronics, Communications and Networks (2012), p.3195.

[4] Y. Xu, H. -B. Pan, S. -Z. He, L. Li: IET Circuits, Devices & Systems Vol. 7 (2013), p.204.

[5] A. Salman, R. Gauthier, W. Stadler, K. Esmark, M. Muhammad, C. Putnam, D.E. Loannou: IEEE Transactions on Device and Materials Reliability Vol. 2 (2002), p.2.

[6] Kwang-Hoon Oh, C. Duvvury, K. Banerjee, R.W. Dutton: IEEE Transactions on Electron Devices Vol. 49 (2002), p.2183.

DOI: 10.1109/ted.2002.803627

[7] Tung-Yang Chen, Ming-Dou Ker: IEEE Transactions on Semiconductor Manufacturing Vol. 16 (2003), p.486.

[8] S. Dong, X. Du, Y. Han, M. Huo, Q. Cui, D. Huang: Electronics Letters Vol. 44 (2008), p.1129.

[9] Haolu Xie, Haigang Feng, Rouying Zhan, Albert Wang, D. Rodriguez, D. Rice: IEEE Electron Device Letters Vol. 26 (2005), p.121.

DOI: 10.1109/led.2004.841860

[10] Chun-Yu Lin, Ming-Dou Ker, Yuan-Wen Hsiao: IEEE International Conference on IC Design and Technology (2010), p.39.

[11] Ming-Hsien Tsai, S.S.H. Hsu, Fu-Lung Hsueh, Chewn-Pu Jou, Ming-Hsiang Song, Jen-Chou Tseng, Tzu-Heng Chang, D. Nag: IEEE International Conference on RFID (2010), p.142.

DOI: 10.1109/nano.2013.6720810

[12] Chih-Yao Huang, Fu-Chien Chiu, Quo-Ker Chen, Ming-Fang Lai, Jen-Chou Tseng: IEEE Transactions on Device and Materials Reliability Vol. 12 (2012), p.113.

DOI: 10.1109/ipfa.2013.6599129

[13] Yu-Ching Huang, Ming-Dou Ker: IEEE Electron Device Letters Vol. 34 (2013), p.674.

[14] Shen-Li Chen and Chun-Ju Lin: Journal of Advanced Materials Research, Vols. 779-780 (2013), p.1124.

[15] Method 3015. 9, MIL-STD 883J (2013), p.561.
