Nonlinear Control of an Inverted Pendulum on a Cart by a Single Control Law

Abstract:

Stabilization at the top vertical position of an inverted pendulum on a cart, while bringing the cart to a desired position, by applying a force to the cart is considered. This is an underactuated mechanical system for which the main nonlinear control scheme, feedback linearization, fails. A single control law producing the force on the cart using cart velocity, and position and velocity of the pendulum is developed and shown, by numerical experiments, to asymptotically stabilize the pendulum at the top position while bringing the cart to its origin, although no attemp is made for a proof of global stability.

• Periodical: Applied Mechanics and Materials (Volume 464)
• Pages: 279-284
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.464.279
• Online since: November 2013
• Authors: Aydın Özbey*, Erol Uzal, Hüseyin Yildiz
• Keywords: Control of Nonlinear Systems, Feedback Linearization, Inverted Pendulum, Underactuated Systems

References

[1] K. Y. Lee, J. H. Ha, J. H Kong and J.S. Kim: Robust Control System Desing for Rotational Inverted Pendulums Using Output Feedback Sliding Mode Controller and Disturbance Observer (Nagoya, Japan, SICE 2001 Jully 25-27).

DOI: 10.1109/sice.2001.977831

[2] K. Pathak, J. Franch and S. K. Agrawal: Velocity And Position Control Of A Wheeled Inverted Pendulum By Partial Feedback Linearization, IEEE Transaction on Robotics Vol: 21 No: 3 (2005).

DOI: 10.1109/tro.2004.840905

[3] R. Lozano, I. Fantoni and D. J. Block: Stabilization Of The Inverted Pendulum Around Its Homoclinic Orbit, Systems and Control Letters 40 (2000) 197-204.

DOI: 10.1016/s0167-6911(00)00025-6

[4] D. Chatterjee, A. Patra and H.K. Joglekar: Swing-Up and Stabilization of A Cart–Pendulum System Under Restricted Cart Track Length, Systems and Control Letters 47 (2002) pp.355-364.

DOI: 10.1016/s0167-6911(02)00229-3

[5] W. T. Pomales and O. R. Gonzales: Nonlinear Control of Swing-Up Inverted Pendulum, Proceedings of the 1996 IEEE International Conference on Control Applications Dearborn, MI, September 15-18., (1996).

DOI: 10.1109/cca.1996.558702

[6] K. J. Aström and K. Furuta, Swing Up a Pendulum by Energy Control (IFAC 13th World Congress, San Fancisco, California, 1996).

[7] M. Bugeja: Non-Linear Swing-Up and Stabilizing Control of an Inverted Pendulum System, (EUROCON 2003 Ljublijana, Slovenia., 2003).

DOI: 10.1109/eurcon.2003.1248235

[8] S. S. Ge, C. C. Hang and T. A. Zhang: Direct Approach to Adaptive Controller Desing and Its Application to Inverted Pendulum Tracking (Proceedings of the American Control Conference, Philadelphia, Pennsylvania, June, 1998).

DOI: 10.1109/acc.1998.703568

[9] R. J. Wai J. D. Lee and L. J. Chang: Development of Adaptive Sliding-Mode Conrol for Nonlinear Dual-Axis Inverted-Pendulum System (Proceedings of the 2003 IEEE/ASME International Conference on Advanced Intelligent Mechatronics, 2003).

DOI: 10.1109/aim.2003.1225447

[10] J. Zhao and M. W. Spong: Hybrid Control for Global Stabilization of the Cart-Pendulum System, Automatica 37 (2001), p.1941-(1951).

DOI: 10.1016/s0005-1098(01)00164-9

[11] A. Shiriaev, A. Y. Pogromsky, H. Ludvigsen and O. Egeland: On Global Properties Of Passivity-Based Control Of An Inverted Pendulum, Int. J. of Robust and Nonlinear Control, chapter 10, pp.283-300, (2000).

DOI: 10.1002/(sici)1099-1239(20000415)10:4<283::aid-rnc473>3.0.co;2-i

[12] W. Zhong and H. Röck: Energy and Passivity Based Control of the Double Inverted Pendulum on a Cart, Proceedings of the 2001 IEEE International Conference on Control Applications, September 5-7, Mexico City.

DOI: 10.1109/cca.2001.973983
