Performance of Tools Design when Helical Milling on Carbon Fiber Reinforced Plastics (CFRP) Aluminum (Al) Stack

Abstract:

Hole making process is not strictly to the drilling technique where others machining could also influence to the quality in CFRP hole.Therefore, helical milling process becomes as an alternative method to produces bore on CFRP plate thus minimizing the defects. The common defects on CFRP are delamination, splintering and cracking. Meanwhile, if the CFRP stacking together with aluminum plate, burr at exit hole of aluminium plate is produced. Therefore, it is essential to control the critical machining parameters to assure a good quality of the hole. The main objective of this project is to improve the hole quality of CFRP/AL stack in terms of surface roughness using helical milling technique. In addition the cutting force and temperature will be measured as well. There are three levels of cutting speeds; two levels of feed rate and depth per helical path are made accordingly to helical milling characteristics. It was found that all tool design exhibit comparable performance for helical milling process on CFRP/Al stack.

• Periodical: Applied Mechanics and Materials (Volumes 465-466)
• Pages: 1075-1079
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.465-466.1075
• Online since: December 2013
• Authors: Erween Abdul Rahim, Z. Mohid, M.R. Hamzah, A.F. Yusuf, N.A. Rahman
• Keywords: Aluminum Stack, CFRP, Helical Milling

References

[1] R. Zitoune, V. Krishnaraj, F. Collombet, Study of Drilling of Composite Material and Aluminum Stack, Composite Structure. 92 (2010) 1246-1255.

DOI: 10.1016/j.compstruct.2009.10.010

[2] W.F. Smith, Principles of Materials Science and Engineering, McGraw-Hill, New York, 1990 699-724.

[3] D. Iliescu, D. Gehin, M.E. Gutierrez, F. Girot, Modeling and tool wear in drilling of CFRP, International Journal of Machine Tools & Manufacture. 50 (2010) 204-213.

DOI: 10.1016/j.ijmachtools.2009.10.004

[4] J. Paulo Davin, Pedro Reis, C. Conceicao Antonio, Drilling Fiber Reinforced Plastics (FRPs) Manufactured by hand lay-up; Influence of matrix, Journal of Materials Processing Technology. 155-156 (2004) 1828-1833.

DOI: 10.1016/j.jmatprotec.2004.04.173

[5] S. Tandon, V.K. Jain, P. Kumar, K.P. Rajukar, Investigations into machining of composites, Precision Engineering. 12 (1990) 227-237.

DOI: 10.1016/0141-6359(90)90065-7

[6] J. Paulo Davim, J. Campos Rubio, A.M. Abrao, A novel approach based on digital image analysis to evaluate the delamination factor after drilling composite laminates, Composites Science and Technology. 67 (2007) 1939-(1945).

DOI: 10.1016/j.compscitech.2006.10.009

[7] Gay D, Hoa SV, Composite materials design and applications. New York: CRC Press (2003).

[8] E.A. Rahim, T. Ogawa, A. Miura, H. Sasahara, R. Koyasu, Y. Yao, Ultrasonic torsional vibration drilling of aerospace structural material, 6th International Conference on Leading Edge Manufacturing in 21st Century, Japan, 8-10 November 2011. (CD-ROM).

DOI: 10.1299/jsmelem.2011.6._3252-1_

[9] E.A. Rahim, H. Sasahara, A study of the effect of palm oil as MQL lubricant on high speed drilling of titanium alloys, Tribology International. 44 (3), 309-317.

DOI: 10.1016/j.triboint.2010.10.032
