Load Sharing Based Fillet Stress Analysis of Involute Helical Gears

Abstract:

The tooth fracture occurs due to high fillet stress developed at the root fillet region along the face width, when the tooth is normally loaded. Hence, an accurate estimation of critical loading position on the tooth along the line of contact for maximum fillet stress and its location along the face width become important to reduce the tooth fracture. In the present work, the maximum fillet stress is evaluated based on load sharing ratio using the finite element method through the multi pair loaded model and using the results, the influence of cutter tip radius and addendum height on the load sharing ratio and respective maximum fillet stress is evaluated. The maximum fillet stress is lesser in the gear drives which is generated by the full round cutter and it increases due to increase the addendum height. The location at which the maximum fillet stress occurs along the face width is determined, when the load is applied at the critical loading position in the helical gear drive.

You might also be interested in these eBooks

4th Mechanical and Manufacturing Engineering

View Preview

Info:

Periodical:

Applied Mechanics and Materials (Volumes 465-466)

Pages:

1234-1238

DOI:

https://doi.org/10.4028/www.scientific.net/AMM.465-466.1234

Citation:

Cite this paper

Online since:

December 2013

Authors:

R. Prabhu Sekar*, G. Muthuveerappan

Keywords:

Addendum Height, Backup Ratio, Cutter Tip Radius, Fillet Stress, Load-Sharing Ratio, Multi Pairs Loaded Model

Export:

RIS, BibTeX

Price:

Permissions CCC:

Request Permissions

Permissions PLS:

Request Permissions

Сopyright:

Citation:

* - Corresponding Author

References

[1] Norihisa ARAI, Masato OEDA and Toshio AIDA, Study on the stresses at the root fillet and safety for slipping of force fitted helical gears, Bulletin of JSME, 24 (1981) 2203-2209.

DOI: 10.1299/jsme1958.24.2203

Google Scholar

[2] Rao and Muthuveerappan. G, Finite element modeling and stress analysis of helical gear tooth, Computers & Structures, 49 (1993) 1095-1106.

DOI: 10.1016/0045-7949(93)90020-e

Google Scholar

[3] Hedlund. J and Lehtovaara. A, Modeling of helical gear contact with tooth deflection, Tribology International, (2006) 613-619.

DOI: 10.1016/j.triboint.2005.11.004

Google Scholar

[4] Rama Thirumurugan and Muthuveerappan. G, Critical loading points for maximum fillet and contact stresses in normal and high contact ratio spur gears based on load sharing, Mechanics based design of structures and mechanics, 39 (2010 ) 118-141.

DOI: 10.1080/15397734.2011.540488

Google Scholar
