Recent Developments in Contra-Flow Crawler in Pipeline

Abstract:

Pipeline Inspection Gauge (PIG) is a device which is inserted into a pipeline and travels throughout the entire length of pipeline and has been used since over 100 years in the petroleum industries to maintain the condition of pipelines mainly for smoothness of production and transportation of hydrocarbon products. Setbacks of conventional PIG; (1) can only move in the direction of the fluid flow, and therefore, (2) they need to be inserted at a specific point in the pipeline during application. This exercise is costly or even dangerous in some circumstances as it requires intervention of human. In order to overcome such difficulties in pigging, several development works of pipeline contra-flow crawler have been developed and aimed at solving the problem of entering and leaving the pipeline from a single exit. The essential bidirectional capability makes it very valuable to many industries, especially the petroleum industries. The objective of this paper is to review the recent developments of contra-flow crawler which has become a continual interest of PIG developers. The review carried out would serve as an industrial application in a form of a quick reference of recent developments in contra-flow crawler in pipeline, and for related industries.

• Periodical: Applied Mechanics and Materials (Volumes 465-466)
• Pages: 784-788
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.465-466.784
• Online since: December 2013
• Authors: Mohamad Azmi Md Haniffa, Fakhruldin M. Hashim
• Keywords: Contra-Flow Crawler, Pigging, Pipeline Inspection Gauge (PIG)

References

[1] M. Hermes. Robotic Inspection Technology – process and toolbox. Rio Pipeline Conference & Exposition. Rio de Janeiro, October (2005).

[2] S. D'Arcy, B. Newman, and G. Broze. A contraflow tehterless mechanical pipeline crawler. Presented at OTC 15259-MS. Offshore Technology Conference. Houston, Texas, May (2003).

DOI: 10.4043/15259-ms

[3] Z. Hu and E. Appleton. Dynamic characteristics of a novel self-drive pipeline pig. IEEE Transactions On Robotics. Vol 21. Pp781-789. (2005).

DOI: 10.1109/tro.2005.852258

[4] K. Swinden. Pigging the unpiggable with next generation thruflow crawlers. December (2010).

[5] W. Liu, M. Zeng, and S. Zhang. Design and kinematical analysis of the contra-flow crawler in pipeline. Presented in Int. Conf. on Electrical and Control Engineering. Yichang China. (2011).

DOI: 10.1109/iceceng.2011.6057766

[6] Z. Wang, and H. Gu. A bristle-based pipeline robot for ill–constraint pipes. IEEE/ASME Transactions on Mechatronics vol. 13. no. 13. (2008).

DOI: 10.1109/tmech.2008.924133

[7] H.J. Chen, B.T. Gao, X.H. Zhang, and Z.Q. Deng. Drive control system for pipeline crawl robot based on CAN bus. Journal of Physics: Conference Series 48. pp.1233-1237. (2006).

DOI: 10.1088/1742-6596/48/1/229

[8] Mohamad Azmi Md Haniffa, and Fakhrul din Mohd Hashim. Recent developments in speed control system of pipeline pigs for deepwater pipeline applications. Presented at WASET Int. Conf. On Computer Electrical, and Systems sciences and Engineering (ICCESSE 2012). K.L. Malaysia. Feb. (2012).

[9] Mohamad Azmi Md Haniffa, and Fakhrul din Mohd Hashim. Review of developments of brush drive mechanism for bidirectional pipeline inspection gauge (PIG) for deepwater pipeline application. Presented at the International Conference on Production, Energy and Reliability (ICPER 2012), KLCC, Malaysia. June (2012).
