Finite Element Analysis of Gear Pair of Main Drive Gearbox Based on Workover Treatment

Abstract:

Considering the fact that the oil well conditions of LIAOHE oil field, the existing structure of the forced lifting and pushing system of work over rig is improved. Main drive gear pair of the forced lifting and pushing system improved is established to study the intensity of contact and modal in the operating process and the dynamic loads based on finite element method. Main failure forms in the condition of low speed and heavy duty is deduced from the distribution of the stress. Also, the maximum allowable stress and natural frequency is obtained. According to the simulation making use of ANSYS, a 3D contact stress analysis of several teeth and modal analysis in dynamic pre-stress of full teeth is illustrated with the rationality of the design.

• Periodical: Applied Mechanics and Materials (Volume 470)
• Pages: 280-283
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.470.280
• Online since: December 2013
• Authors: Jia Qi Jin, Le Yu*, Xian Rong Wang
• Keywords: Contact Analysis, Forced Lifting, Helical Gear Pair, Modal Analysis, Pushing System

References

[1] Chungong Qin: Auto variable analysis and evaluation of gear strength [D] master degree theses of master of jilin university, chapter 3, (2011).

[2] Mingjiang Wang, Yongmei Zhu, Wenxin Liu: Finite element meshing method research [J]. Journal of mechanical design and manufacturing, 2004 (1) : 22-24.

[3] Editorial underground work technical data manual: Downhole operation technical data handbook [M]. Beijing petroleum industry press, (2000).

[4] Jinyuan Tang, Huizhou Chen: The rain gear meshing contact impact analysis [J]. Journal of mechanical engineering, 2011, 47 (7) : 22 to 30.

[5] Caichao Zhu, Qian Tang , Guxu Wang, etc: Dynamic characteristic of the new type reducer [J]. Journal of mechanical engineering, 2008, 44 (4) : 58-62.
