Numerical Simulation of the Effect of the Uneven Wall on the Liquid Film Flow

Abstract:

Two-dimensional models of inclined flat and corrugated walls are established based on VOF method to numerically simulate the flow characteristics of liquid film. The impact of wall structures on the wave profile of the film is studied. The results indicate that the wall structure plays an important role on the liquid film, there are vortexes generated on the trough of wavy wall, the vortex has the "rolling" effect in machinery, which reduces the viscous resistance. and continuous film is easier to form on the wall whose corrugated size is smaller.

• Periodical: Applied Mechanics and Materials (Volumes 477-478)
• Pages: 232-235
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.477-478.232
• Online since: December 2013
• Authors: Mei Liu*, Yongxin Zhu, Song Ling Wang
• Keywords: Flow Characteristic, Inclined Uneven Wall, Liquid Film, Numerical Simulation, VOF

References

[1] YE Xue-min, ZHANG Ying, WANG Song-ling, et. al. Investigation on Stability of Sheared Wavy Liquid Films: Proceedings of the CSEE, Vol. 27(20) (2007), p.103.

[2] LU Chuan, DUAN Ri-qiang, JIANG Sheng-yao. Experimental study of flow instabilities of falling films: J. Tsinghua Univ (Sci & Tech), Vol. 48(9)(2008) , p.107.

[3] SONG Jian, HU Po, WEI Sheng-jie, et. al. Experimental Study on Surface-Wave Evolution Behavior of Water Film Falling Down Vertical Plate: Atomic Energy Science and Technology, Vol. 46(7) (2012), p.804.

[4] June Kee Min, Il Seouk Park. Numerical study for laminar wavy motions of liquid film flow on vertical wall: Int. J. Heat Mass Transfer. Vol. (54) (2011), p.3056.

DOI: 10.1016/j.ijheatmasstransfer.2011.04.005

[5] Alexandre Ern, Rémi Joubaud, Tony Lelièvre. Numerical study of a thin liquid film flowing down an inclined wavy plane : Phys. D: Nonlinear Phenom, Vol. 240(21) (2011) , p.1714.

DOI: 10.1016/j.physd.2011.07.007

[6] SHI Jin-sheng. An Investigation of Evaporation Heat Transfer for a Laminar Falling Film along a Vertical Corrugated Plate Surface: Chinese Quarterly of Mechanics, Vol. 27(4) (2006), p.493.

[7] Beata Szulczewska, Ireneusz Zbicinski, Andrzej Gorak. Liquid Flow on Structured Packing CFD Simulation and Experimental Study. Vol. 26(5) (2003), p.580.

DOI: 10.1002/ceat.200390089

[8] LIU Yu-feng, TONH Yi-jun, RenHaigang. Numerical Investigation on Flow characteristics of Falling Water Film Down a Vertical Plate at High Reynolds Number : Infrared Technology. Vol. 32(10) (2010) , p.567.

[9] GU Fang. CFD Simulations of the Local-Flow and Mass-Transfer in the Structured Packing: Tianjin: Tianjin University. (2004).

[10] SUN Feng-dan. Numerical simulation on liquid flow characteristics of the wavy plate: Modern Chemical Industry, Vol. 32(1) (2012), p.90.

[11] PAK Myong-il, HU Guo-hui. Influences of Wall Topography on Unsteady Free Surface Waves in Film Flow: Chinese Journal of Computational Physics, Vol. 28(6) (2011), p.843.
