Finite Element Analysis of Input Axis in Six-Speed Transmission

Abstract:

The joint simulation of Virtual Prototype Technology and Finite Element Method was utilized to perform the analysis of both strength and fatigue life of the input axis in a six-speed vehicle transmission with three axes. Firstly, the software Pro/E was used to establish a 3-D model of the input axis and its gear engagement, and the model was then imported into a software ADMAS of the virtual prototype technology to perform a dynamic simulation analysis. Secondly, the gear contact forces obtained by above-mentioned analysis were used as the loading condition of finite element analysis of the input axis to check its strength. Finally, the fatigue of meshing teeth on the input axis was analyzed to determine the fatigue life of the input axis. The results show that the static strength of input axis can meet the requirement of safe use under the working condition of input torque T=1.5kN·m, and the minimum fatigue life on the place where the stress is maximum at flexural root of a tooth is about 2 million times.

• Periodical: Applied Mechanics and Materials (Volumes 477-478)
• Pages: 45-48
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.477-478.45
• Online since: December 2013
• Authors: Qing Dun Zeng*, Xin Pan
• Keywords: Fatigue Life, Finite Element Method (FEM), Gearbox, Input Axis, Strength, Virtual Prototype Technology
