Fuzzy Recognition Method and Simulation Analysis on Second Harmonic Excitation Inrush Current of Transformer

Abstract:

With the rapid development of electric power industry in our country, the extra-high voltage power transmission system is widely applied so that the power transformer plays a more and more important role. This not only requires the transformer to quickly protect the circuit system but requires the transformer to be sensitive and reliable. Generally speaking, the method of differential protection is used to deal with some troubles when it breaks down such as the faster actuation time and wrong operation in magnetizing inrush current according to the second harmonic principle and waveform symmetry principle. On the basis of using second harmonic principle, we try to introduce the fuzzy recognition technology and provide a new criterion for the interlock of second harmonic by constructing the function subordination. Finally the simulation analysis is made through MATLAB, whose effect is better.

• Periodical: Applied Mechanics and Materials (Volumes 484-485)
• Pages: 1076-1080
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.484-485.1076
• Online since: January 2014
• Authors: Jiao Dong Wu
• Keywords: Differential Protection, Excitation Inrush Current, Fuzzy Recognition, Transformer

References

[1] Yuan Yubo, Lu Yupin, Li Cheng, Xu Yang. Research on the adaptive second harmonic excitation inrush current braking scheme based on additional phase discrimination [J]. Proceedings of the CSEE, 2006, 26 (18): 19-24.

[2] Wang Zuguang, Ren Jie, Chou Xinhong, etc. New principle of transformer differential protection harmonic atresia. Automatic system [J] 2006, 30 (14): 50-53.

[3] BiDaqiang, Wang Xiangxi, Yang Huihong, Wang Weijian. Analysis of current phase compensation methodin transformer differential protection [J]. Automation of electric power systems, 2006, 30 (18): 33-37.

[4] Dong Jie, Yu Liping, JiaoZhixian, Xu Huaqiao. Research on the braking principle of transformer differential protection current [J]the electric power system automation, 1997, (12): 30-33.

[5] Wang Weijian. The principle and application of main electrical equipment relay protection [M]. China electric power press, 1999: 235-239.

[6] Fan Wentao, Wang Guangyan. A new criterion of transformer microcomputer differential protection based on fuzzy set theory [J]. Journal of Chinese electrical machine engineering, 1997 (6): 403-407.

[7] Xu Jianzheng. Transformer microcomputer differential protection of fuzzy scalar product braking principle [J]. Journal of relay, 2001, 30 (9): 46-49.

[8] ZongHongliang, Jin Huafeng Zhu Zhenfei, etc. Transformer excitation inrush current identification method based on the excitation impedance change [J]. Proceedings of the csee, 2002, 21 (7): 91-94.
