Research on the New Combined Type Crusher Hammer

Abstract:

To solve the problems of installed trival, resource waste, hammerhead falling off and improve the poor abrasion resistance of hammer handle under the crusher hammers working condition, the new combined type crusher hammers were designed by connecting separated hammer handle and separated hammer head. When hammer head were worn badly, we just replaced hammer head and don't have to remove the shaft rod. This design can save a lot of time and labor force, improve production efficiency and we can save a lot of resources by reusing the hammer handle; At the same time, hammer tip was casted with liquid-liquid bimetal composite casting technology of casting, under the premise of guaranteeing the wear-resisting, which can also ensure that the impact toughness of the joint. Validated by actual working condition, hammer handle can be replaced at least five times for this design of hammer, and each group has 24 hammer heads, every 5 sets of hammer heads can save 1200 kg metallic materials, 1800 KWh and CO² emissions dropped by 1795 kg.

• Periodical: Applied Mechanics and Materials (Volumes 488-489)
• Pages: 1160-1164
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.488-489.1160
• Online since: January 2014
• Authors: Xing Ming Zhao*, Hai Tao Zhou, Shou Fan Rong, Bao Guo Yang, Chun Hong Li
• Keywords: Bimetal, Combined Type, Crushing Hammers

References

[1] Huang Jun-ping, Zhou Hong-yi, Bai Zhan-wei, et al. Failure analysis of crush hammers based on damage fracture energy [J]. Chongqing University Eng Ed, 2009, 8(2): 105-111.

[2] Qin Jin-song, He Bai-ling. Plane casting technology for high chromium cast/carbon steel composite plate [J]. Hot working technology, 2004, (5): 33-34.

[3] Shoufan Rong, Jiwei Guo. Influence of Casting Technique on the Mechanical Properties of Bimetal Composites [J]. Journal of Iron and Steel Research, International, 2011, 18(1): 546-549.

[4] Shen Da-dong, Jin Bao-shi, Wang En-lu. Austenrte-bainite steel hammers with inserted high chrome cast iron [J]. Hot working technology, 2003, (4): 582-601.

[5] Zhang Heng-da, Liu Zi-an. The connection mechanism of cast iron-cemented carbide by composite casting [J]. Foundry, 2000, (49): 6-8.
