The Development of Excelle Lighting and Signal Test Rig

Abstract:

The lighting and signaling system test rig of the GM Excelle is selected to develop lighting rig, and is designed according to the circuit diagram of the system real cars and real cars positions. This rig have a system diagram, the fault controller, fault detection interface. In actual use, a single fault type can be set, and multiple fault types can be set, too. Failure points of each fault type can also be arbitrarily set according to the situation of the student grasping, which is more conducive to cultivating diagnostic ideas of the students and improving their troubleshooting ability. It is an economical, practical and efficient experimental teaching equipment.

• Periodical: Applied Mechanics and Materials (Volumes 488-489)
• Pages: 1152-1155
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.488-489.1152
• Online since: January 2014
• Authors: Xi Wei Zheng*
• Keywords: Fault Controller, Lighting System Test Rig, Signaling System Test Rig, Troubleshooting Ability

References

[1] Tom Denton: Automobile Electrical and Electronic Systems, SAE. (1995).

[2] Zhisheng Yu, In Chinese: Car theory, Mechanical Industry Publications(2008).

[3] Buick Excelle Service manual.

[4] Xianhui Zhang, In Chinese: Automobile Electric System Detecting and Servicing, Chemical Industry Publications(2010).

[5] Xinghua Pang, In Chinese: Mechanical Design, Electronics Industry Publications (2010).

[6] Xiaofeng Bao, In Chinese: Car experiments and testing, Mechanical Industry Publications (1995).

[7] Guoping Yao, In Chinese: Santana 2000/Santana Electric System using and servicing, Beijing University of Technology Publications(1999).

[8] Lianfu Yang, In Chinese: Automobile Electric System Servicing, Machinery Industry Publications (2009).

[9] Haibin Yao, InChinese: Electrician technology, Higher Education Publications (1999).
