Numerical Simulation Method for Fluid-Structure Interaction in Compressor Blades

Abstract:

A simulation method for fluid-structure interaction (FSI) in compressor blades was discussed to predict the aeroelastic stability of blades. Using the MFX, which is a Multi-Field Solver in ANSYS, the total force of computational fluid dynamics (CFD) have been interpolated to computational structural dynamics (CSD) grids, and then the vibration displacements of CSD nodes have been interpolated to CFD grids at the blade surface. In CFD analysis, the grid coordinates of the moveable region have been updated by multi-layer moving grid technique, and the finite volume method has been applied to calculate the Reynolds-averaged Navier-Stokes (RANS) equations closed by k-E turbulent model. For NASA Rotor 67, detect the displacement response of compressor blades at the design speed , and the aeroelastic stability of blades has been analyzed preliminarily. The study shows that the FSI procedure is feasible to predict the aeroelastic stability of compressor blades.

• Periodical: Applied Mechanics and Materials (Volumes 488-489)
• Pages: 914-917
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.488-489.914
• Online since: January 2014
• Authors: Xue Feng Li*, Xiu Quan Huang, Chao Liu
• Keywords: Aeroelastic Stability, ANSYS-CFX, Compressor Blade, Fluid Structure Interaction (FSI), Multi-Layer Moving Grid Technique
