Modal and Harmonic Response Analysis: Linear-Approach Simulation to Predict the Influence of Granular Stiffeners on Dynamic Stiffness of Box-Shaped Workpiece for Increasing Stability Limit against Chatter

Abstract:

Chatter is a self-excited vibration that occurs during machining process. It becomes a limitation to productivity and reduces the surface quality of work piece. Increasing dynamic stiffness of the work piece will improve its stability limit against chatter occurrence.Initial linear-approach simulation performing finite element modal and harmonic response analysis of the work piece filled with granular stiffener (sand and gravel) is presented. Drucker-Prager granular frictional material model is chosen to represent sand and gravel used as stiffener. Drucker-Prager parameters are chosen based on the experiment setting condition.Effect of an addition of the granular stiffener on the dynamic stiffness of the work piece will be evaluated. The simulation results are verified by experiment results.

• Periodical: Applied Mechanics and Materials (Volume 493)
• Pages: 501-506
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.493.501
• Online since: January 2014
• Authors: Oegik Soegihardjo, Suhardjono Suhardjono, Bambang Pramujati, Agus Sigit Pramono
• Keywords: Chatter, Dynamic Stiffness, Harmonic Response Analysis, Modal Analysis

References

[1] Siddhpura, M. and Paurobally, R., A Review of Chatter Vibration Research in Turning., International Journal of Machine Tools & Manufacture Vol. 61 (2012), pp.27-47.

DOI: 10.1016/j.ijmachtools.2012.05.007

[2] Quintana, G. and Ciurana, G., Chatter in Machining Process: A Review., International Journal of Machine Tools & Manufacture, (2011).

DOI: 10.1016/j.ijmachtools.2011.01.001

[3] Hung, J.P., et. al., Finite Elemen Prediction on the Machining Stability of Milling Machine with Experimental Verification., World Academy of Science, Engineering and Technology, Vol. 72 (2010).

[4] Catania, G. and Mancinelli, N., Theoretical-experimental modeling of milling machines for the prediction of chatter vibration., International Journal of Machine Tools & Manufacture, (2011).

DOI: 10.1016/j.ijmachtools.2010.11.008

[5] Choudhury, S.K., and Mathew, J., Investigations of the Effect of Non-uniform Insert Pitch on Vibration During Face Milling., International Journal of Machine Tools & Manufacturing, Vol. 35, No. 10 (1995), pp.1435-1444.

DOI: 10.1016/0890-6955(94)00131-3

[6] Koenigsberger, F. and Tlusty, J., Machine Tool Structures., Volume 1, 1st edition, Pergamon Press Ltd, (1970).

[7] Suhardjono, et al., Karakteristik Dinamik Kolom Baja yang Diisi Pasir, Kerikil atau Serbuk Gergaji Besi., Jurnal Teknik Mesin - Universitas Kristen Petra, Surabaya, Vol. 10, No. 2, Oktober (2008).

[8] Soegihardjo, O., et al., Upaya Menghindari Chatter pada Proses Face Milling dengan Penambahan Stiffener pada Benda Kerja Berbentuk Kotak., Prosiding Seminar Nasional Teknik Mesin 7, Surabaya, Indonesia, (2012).

DOI: 10.9744/jtm.14.1.40-46

[9] Wibowo, O.J., Pengaruh Volume Pasir atau Kerikil Terhadap Chatter pada Proses Mengefreis Tegak untuk Benda Kerja Berbentuk Kotak., Tugas Akhir, Jurusan Teknik Mesin, FTI Institut Teknologi Sepuluh Nopember Surabaya, (2006).

DOI: 10.24089/j.sisfo.2016.09.005

[10] Zaveri, K., Modal Analysis of Large Structures – Multiple Exciter Systems, 1st edition, 2nd print., Bruel & Kjaer, November (1984).

[11] Lim, A.J.M.S., et al., The Integration of the Morphological Aspects of Sand to It's Shear Strength and Dilatancy Characteristics. International Journal of Integrated Engineering Vol. 4 No. 2 (2012) pp.77-87.

[12] Cerato, A.B., Scale Effects of Shallow Foundation Bearing Capacity on Granular Material. PhD Dissertation, University of Massachusetts, Amherst, February (2005).

[13] Barrios, D.O.S., Determination of Soil Poperties for Sandy Soils and Road Base at Riverside Campus Using Laboratory Testing and Numerical Simulation., Thesis, Graduate Studies, Texas A&M University, (2010).
