Finite Element Analysis of a Forklift Truck Mast System

Abstract:

The finite element method (FEM) has been used for an independent analysis of forklift truck components. However, the accuracy of such an analysis may not be reliable because it does not in view of the interaction of the forces transferred between components. Here, we analyze the mast system as a whole using an FEM based on a simulation chain method employing MPC184 units, as well as a method to analyze components independently. Both methods are used to simulate the stress of the upper beam of the inner mast. We then compare the maximum stresses calculated using the two different methods under three sets of working conditions. The data show that, in comparison with theoretical results, the average error rate of the overall analysis method was 4.71%, while that of the independent analysis was 33.3%.

• Periodical: Applied Mechanics and Materials (Volumes 494-495)
• Pages: 668-672
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.494-495.668
• Online since: February 2014
• Authors: Yuan Zhuang, Zhong De Shan*, Qian Zhang
• Keywords: Bearing Model, Finite Element Method (FEM), Forklift Truck Mast

References

[1] HAO Qingjun, GUO Shunsheng. Finite Element Analysis of Riveting Characteristic of Double-layer Longitudinal Beam of Vehicle Frame [J].  MECHANICAL ENGINEERING & AUTOMATION, 2009, (5): pp.71-73.

[2] HAN Lei. Finite element analysis of forklift truck mast structure based on ANSYS [J]. Technological Development of Enterprise, 2012, 31(2): pp.30-31.

[3] ZHOU Jingjing, MU Xihui, MA Zhenshu, et al. Finite element analysis and dynamic simulation of multi-direction side-loading forklift truck's mast [J].  HOISTING AND CONVEYING MACHINERY, 2009, 23(2): 65-68.

[4] Hanno Niemann, Joseph Morlier, Amir Shahdin, et al. Damage localization using experimental modal parameters and topology optimization[J]. Mechanical Systems and Signal Processing, 2010, 24(3): 636-652.

DOI: 10.1016/j.ymssp.2009.10.022

[5] SHEN Li-fang. Finite Element Analysis for the Structure of Portal Frame of Fork Lifter Based on ANSYS [J]. COMPUTER KNOWLEDGE AND TECHNOLOGY, 2008, 20 (3): 383-385.

[6] ZHANG Qian, SHAN Zhongde, ZOU Ailing, et al., The application of high strength steel in the lightweight design of forklift outside door frame [J]. Construction Machinery and Equipment, 2013, 44(2): 20-24.

DOI: 10.1049/cp.2011.1040

[7] Yi Z, Sun S. FEM Simulation for Working Device of ZLK15 Loader[C]. Computer Modeling and Simulation, 2010. ICCMS'10. Second International Conference on, 2010, 3: 186-189.

DOI: 10.1109/iccms.2010.412

[8] LIU Hongwen. Mechanics of Materials (I) [M]. Beijing: Higher Education Press. 2004: 138-253.
