Study on Enhanced Heat Transfer and Structural Optimum for Combination Vortex Generator in Spiral Channel

Abstract:

The array configuration of delta wing and elliptical cylinder vortex generator in the spiral surface channel was studied. By changing the assembly distance s, the triangle wing vortex generator angle of attack α, the elliptical cylinder vortex generator angle of attack β to research the heat transfer and resistance properties under different working conditions. The research model as follow: the heat-medium is water-vapor [H₂, the cold medium of flow is air, Steam temperature is 400K and air inlet temperature is 293K, the Reynolds number ranging from 4000 to 7000.The optimum structure was determined by using numerical simulation method and orthogonal experiment method. The result shows the optimization structure of the combination vortex generator: α=45°, β=45°, s=90mm. Compared with the normal structure, the heat transfer enhancement comprehensive effect of the optimization structure raised about 36.2%~47.6%.

• Periodical: Applied Mechanics and Materials (Volumes 501-504)
• Pages: 2338-2343
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.501-504.2338
• Online since: January 2014
• Authors: De Fan Qing, Ya Long Zhang, Sheng Xue Liu, Cui Fang Wang
• Keywords: Combination Vortex Generator, Enhanced Heat Transfer, Optimum Structure, Spiral Surface Channel

References

[1] Jing L, Zhongzheng Wang. Heat transfer enhancement by winglet longitudinal vortex generator technology [J]. HV&AC, 2001, 31(5): 47-48. (In Chinese).

[2] Joardar A，Jacobi A. Impact of leading edge delta-wing vortex generators on the thermal performance of a flat tube, louvered-fin compact heat exchanger [J]. Int J Heat Mass Transfer, 2005, 48: 1480-1493.

DOI: 10.1016/j.ijheatmasstransfer.2004.10.018

[3] Chen Y, Fiebig M, Mitra N K. Heat transfer enhancement of finned oval tubes with staggered punched longitudinal vortex generator [J]. International Journal of Heat and Mass Transfer，2000, 43: 417-435.

DOI: 10.1016/s0017-9310(99)00157-x

[4] Jiansheng Wang, Zhiyi Liu, Jinfeng Zhang, et al. Large Eddy Simulation on Heat Transfer Enhancement of Inclined-Cut Ellipsoidal Vortex Generator [J]. Chinese Journal of Mechanical Engineering. 2007. 43 (10): 55-61. (In Chinese).

DOI: 10.3901/jme.2007.10.055

[5] Feng Qiu, Bo Gu, Weiping Zeng et al. Simulation on Heat Transfer and Pressure Drop of R410A Two-phase Flow in Plate Heat Exchanger[J]. Journal of Refrigeration2010, 31(1): 39-44. (In Chinese).

[6] Cuifang Wang, Shengxue Liu. Heat transfer enhancement research in spiral plate heat exchanger with combination of vortex generator [J]. Mechanical Research & Application 2012, 120(4): 29-32. (In Chinese).

[7] Chu P, He Y L, Lei Y G, et al. Three-dimensional numerical study on fin-and-oval-tube heat exchanger with longitudinal cortex generators[J]. Applied Thermal Engineering, 2009, 29(5/6): 859-876. (In Chinese).

DOI: 10.1016/j.applthermaleng.2008.04.021

[8] Jin Wei, Chengying Qi, Numerical Study on Longitudinal Vortex Generation and Heat Transfer Enhancement [J]. Journal of Hebei University of Technology, 2006, 35 (6): 88-91. (In Chinese).

[9] Zeliang Yang, Xinying Wu. Numerical Simulation of Natural Heat Convection on Vertical Plate Reinforced with Longitudinal Vortex [J]. Journal of South China University of Technology (Natural Science Edition). (In Chinese).

[10] Zonghu Lin. Heat transfer enhancement and engineering application [M]. BeiJing: China Machine Press, 1987. (In Chinese).
