Experimental Research of Performance of a New Fabricated Lightweight Steel-Concrete Composite Floor

Abstract:

For study of mechanical property of a fabricated composite floor consisting of thin-walled steel I beams and lightweight aggregate concrete panels, the static load experiment of the new composite floor was presented and the results was discussed. The specimen was simply supported at the two shorter sides and the other two longer sides free. The equivalent uniform loads are applied to the floor through setting the load blocks on the supper surface of the floor. The vertical displacements, slips between steel beam and concrete panel and strains of the specimen were measured. It was shown that the strain at the bottom of the concrete panel is quite close to the strain at the top flange of the main beam and the strain at bottom flange of the main beam is much larger than the value at top flange.

• Periodical: Applied Mechanics and Materials (Volumes 501-504)
• Pages: 787-790
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.501-504.787
• Online since: January 2014
• Authors: Xin Tang Wang, Bing Shao, Zheng Jue Huang
• Keywords: Experimental Research, Fabricated Panel, Lightweight Composite Floor, Thin-Walled Steel Beam

References

[1] M. J. Bai, Y. J. Shao, X. H. Wen and R. B. She: Concrete and Cement Products 5(2011), p.43.

[2] Y. Zheng, S.W. Cheng and W. H. Deng: Industry Construction Vol. 37(2007), p.579.

[3] Y. Hao, J.J. Miao, Y.C. Liu and G.Q. Sun: Building Structure Vol. 38(2008), p.25.

[4] C.Z. Ding: Light Steel Skeleton House (Machinery Industry Press, Beijing 2007).

[5] L.F. Jorge, J. Schänzlin, S.M.R. Lopes, H. Cruz and U. Kuhlmann: Engineering Structures Vol. 32(2010), p.3966.

DOI: 10.1016/j.engstruct.2010.09.007

[6] W. A. Thanoon, Y. Yardim and M.S. Jaafar: Construction and Building materials Vol. 24(2010), p.2224.
