Effect of the Thick-Walled Steel Tubular Joint Stiffness on the Overall Stability of a Single-Layer Latticed Shell

Abstract:

As a new type of joint, the thick-walled steel tubular joint is applied in the single-layer latticed shell to solve the connectivity problem of rectangular tube. In combination with the design of practical project, the effect of the new joint stiffness on the overall stability of a single-layer latticed shell and the value of joint stiffness are studied by ANSYS. Some parameters as the rectangular tube section, the thickness of thick-walled steel tube and connecting plate are taken into account in the process of geometric nonlinear analysis. The results show that joint stiffness has great influence on the overall stability of a single-layer latticed shell and the range of effect gradually increases with the growth of rectangular tube section.

• Periodical: Applied Mechanics and Materials (Volumes 501-504)
• Pages: 791-795
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.501-504.791
• Online since: January 2014
• Authors: Lan Chen*, Bo Yin
• Keywords: Geometric Nonlinearity, Joint Stiffness, Latticed Shell, Parameter Analysis, Stability

References

[1] Xinmin Wang. ANSYS numerical analysis of engineering structures, Beijing: People's Communications Press (2011). (In Chinese).

[2] Zhihua Chen, Hongbo Liu, Ting Zhou. APDL parametric calculation and analysis [M], Beijing: China Water & Power Press(2009). (In Chinese).

[3] Jingle Zhang: Latticed shell joint stiffness and its impact on the overall stability, Master's degree thesis (2003). (In Chinese).

[4] Code for design of steel structure [S]. GB 5007-2003 (In Chinese).

[5] Technical specification for space frame structure [S]. JGJ 7-2010 (In Chinese).

[6] Shizhao Shen, Xin Chen: Stability of Latticed Shell Structures, Beijing: Science Press (1999). (In Chinese).
