Non-Destructive Evaluation of Reinforcing Rebar Radius by Digital Image GPR Technique

Abstract:

Ground Penetrating Radar (GPR) is a high efficiency technology to detect the cylindrical medium in the concretes material. The electromagnetic wave is incidental to double-rebar, and measures the reflection signal behaviors from energy zone. The results from the reflection signal of electromagnetic wave of the reinforcement concretes allow evaluating the radius of double-bar (1.6cm, 1cm). A physical model can effectively measure the radius of double-bar by the result of electromagnetic wave reflex behavior analysis. The results indicate that, this techology is capable of estimating the reinforcing double-bar radius to within 6%.

• Periodical: Applied Mechanics and Materials (Volumes 501-504)
• Pages: 847-851
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.501-504.847
• Online since: January 2014
• Authors: Che Way Chang*, Chen Hua Lin, Shyi Lin Lee, Ping Huang Chen, Ching Cheng Jen, Huei Lin Chen
• Keywords: Double-Rebar, Ground Penetrating Radar (GPR), Power Reflection Coefficient

References

[1] Grieve R. Proceedings of the 2004 International Symposium on Safety Science and Technology, 2004; 4: 2340-2346.

[2] Al-Nuaimy W, Shihab S, Eriksen A. Proceedings of the Tenth International Conference Ground Penetrating Radar, GPR 2004; 1: 359-362.

[3] Shaw MR, Molyneaux TCK, Millard SG, Taylor MJ, Bungey JH. Insight: Non-Destructive Testing and Condition Monitoring, 2003; 45(12): 813-816.

DOI: 10.1784/insi.45.12.813.52980

[4] Chang CW, Lin CH, Lien HS. Construction and Building Materials, Volume 23, Issue 2, February 2009; 23(2): 1057-1063.

[5] Soldovieri F, Persico R, Utsi E, Utsi V. NDT&E International , 2006; 39: 602–607.

DOI: 10.1016/j.ndteint.2005.12.005
