Research on Infrared Thermal Imaging Technique for the Sidewall of LNG Storage Tank

Abstract:

Liquefied natural gas (LNG) is obtained by cooling the gas temperature to -162 degree. Problems with the steel cans, the insulation layer or the concrete tank of the LNG tank can lead to changes of the temperature, local temperature decreases, and the safety of the tank is threatening. Through the combination of many sets of infrared thermal imager to monitor the temperature of the LNG storage tank’s sidewall, analyze the heat imagine, establish the corresponding relationship between the locations on the sidewall of the LNG tank and on the heat imagine, determine the position of the temperature point on the tank wall. Infrared thermal imaging technique for the sidewall of LNG storage tank can find out the heat abnormal conditions and fixing the temperature drop area in time, and provide powerful guarantee for the safe storage of the liquefied natural gas.

• Periodical: Applied Mechanics and Materials (Volumes 511-512)
• Pages: 425-428
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.511-512.425
• Online since: February 2014
• Authors: Jie Jiang, Wen Da Zhu, Gong Sheng Yang, Jing Peng Yan, Nan Jin Gao, Lei Zhao, Qing Zhang*
• Keywords: Infrared Thermal Imager, Liquefied Natural Gas (LNG), Location, Sidewall

References

[1] Dawei Men. New Technologies and Products in Chinese Vol. 02 (2012), p.65.

[2] Juan Su, Meizhen Zhou, Jianxing Yu, et al. Cryogenics in Chinese 04(2010), pp.47-52.

[3] Yangyang Wang, Xiumu Fang, Yanping Li and Baoli Zhang. HV&AC in Chinese Vol. 36(2006), pp.84-88.

[4] Yahong Zheng and Jinyu Liao. Journal of Shenyang University of Technology in Chinese Vol. 28(2006), pp.446-470.

[5] Sihua Zhao, Qing Zhang and Jiaqi Zhao. Computer Technology And Development Vol. 157-158(2012), pp.194-197.
