Tri-Band Bandpass Filter Using Open Loop Resonator Loaded by One Stub with Three Branches

Abstract:

To obtain an adjustable passband filter, one open stub with three branches is loaded on an open loop resonator. The first and the third passband frequencies of the tri-band filter can be flexibly controlled by tuning lengths of three branches, whereas the second passband frequency is fixed. The fabricated filter has good tri-passband performance at 2.19, 4.26, 6.30 GHz. Measured results agree well with the simulated ones.

• Periodical: Applied Mechanics and Materials (Volumes 513-517)
• Pages: 2791-2794
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.513-517.2791
• Online since: February 2014
• Authors: Xing Bing Ma*, Feng Shan Zhang, Cai Feng Liang
• Keywords: Bandpass Filter, Open Loop Resonator, Three Branches, Tri-Band

References

[1] F. C. Chen, Q. X. Chu and Z. H. Tu: Electronics Letters, vol. 44 (2008) No. 12, p.747.

[2] Q. X. Chu and X. M. Lin: Electronics Letters, vol. 44 (2008) No. 4, p.295.

[3] C. I. G. Hsu, C. H. Lee and Y. H. Hsieh: IEEE Microwave and Wireless Components Letters, vol. 18 (2008) No. 1, p.19.

[4] J. Xu, C. Miao, L. Cui, Y. X. Ji and W. Wu: Electronics Letters, vol. 48 (2012) No. 1, p.28.

[5] J. Z. Chen, N. Wang, Y. He and C. H. Liang: Electronics Letters, vol. 47 (2011) No. 15, p.858.

[6] X. B. Ma and H. X. Zheng: Microwave and Optical Technology Letters, vol. 54 (2012) No. 8, p.1817.

[7] X. Guan, X. Wang, B. Wang, Y. Yuan and H. Liu: Progress in Electromagnetics Research Letters, vol. 34 (2012), p.65.
