A Novel RFID Tag Dipole Antenna

Abstract:

There is a problem in normal meander line antenna (MLA) that it is difficult to get performances of miniaturization, high efficiency and high inductance at the same time. A simple novel antenna design for this challenge is described. Two capacitive loads are added at the end of MLA to adjust the impendence. For saving material, holes are digged on the loads. Simulation by HFSS shows that, comparing with the regular MLA, the proposed antennas impedance enhances from 10-12j to 23+150j, and the maximum gain enhances from 1.31dB to 1.67dB, with a read range of 10.1m. Meanwhile the return loss at 915MHz is-34dB, with a wide-10dB bandwidth of 860 ~ 985 MHz.

• Periodical: Applied Mechanics and Materials (Volumes 513-517)
• Pages: 2808-2811
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.513-517.2808
• Online since: February 2014
• Authors: Ming Lu He, Yan Bing Xue*, Jing Zhang
• Keywords: Capacitive Load, Meander Line Antenna, RFID

References

[1] Carla.R. M, Jorge.R. C, Carlos A.F. Passive UHF RFID Tag for Airport Suitcase Tracking and Identification[J]. IEEE Antennas and Wireless Propagation Letters, 2011, 10: 123-126.

DOI: 10.1109/lawp.2011.2112326

[2] Van Hieu Nguyen, Hong Phuong Phan, Manh Ha Hoang. Improving Radiation Characteristics of UHF RFID Antennas by Zigzag Structures [C]. International Conference on Advanced Technologies for Communications, (2011).

DOI: 10.1109/atc.2011.6027445

[3] Naobumi Michishita, Yoshihide Yamada. A Novel Impedance Matching Structure for a Dielectric Loaded 0. 05 [C]. Antennas and Propagation Society International Symposium, (2006).

DOI: 10.1109/aps.2006.1710795

[4] W. Choi, H.W. Son, C. Shin. RFID tag antenna with a meandered dipole and inductively coupled feed [J]. Electronics and Telecommunications Research Institute, 2006: 619-622.

DOI: 10.1109/aps.2006.1710600

[5] K.V.S. Rao, P.V. Nikitin, S.F. Lam. Antenna Design for UHF RFID Tags: A Review and a Practical Application [J]. IEEE Transaction On Antennas And Propagation, 2005. 12, 53(12): 3870-3877.

DOI: 10.1109/tap.2005.859919

[6] B. Yang, Q. Feng. A Folded Dipole Antenna for RFID Tag [J] . IEEE, (2008).

[7] L. Catarinucci, R. Colella, L. Tarricone. Enhanced UHF RFID Sensor-Tag [J]. IEEE Microwave and Wireless Components Letters, 2013. 2, 23(1): 49-51.

DOI: 10.1109/lmwc.2012.2234092

[8] Ferran Paredes, Gerard Zamora, Francisco Javier Herraiz-Martínez, Ferran Martín, Jordi Bonache. Dual-Band UHF-RFID Tags Based on Meander-Line Antennas Loaded With Spiral Resonators [J]. IEEE Antennas and Wireless Propagation Letters, 2011, 10: 768-771.

DOI: 10.1109/lawp.2011.2162716

[9] D.M. Dobkin. The RF in RFID: Passive UHF RFID in Practice [M]. Newnes is an imprint of Elsevier, (2007).
