Cymbal Piezoelectric Composite Transducer for Soccer Robot Attitude Detection Application

Abstract:

This paper proposed a soccer robots attitude detection method based on the principle and vibration mode of cymbal piezoelectric composite transducer. Cymbal piezoelectric composite transducers and MEMS-based three-axis low-g sensor were set on some different support points of soccer robot's joint to accomplish attitude detection. The signal processing circuit and algorithm software were designed. The research results showed that the performance parameters of the soccer robot falling down attitude detection system based on cymbal piezoelectric composite transducer are better than the other sensor, such as the sensitivity, correct, undetected fall and stability duration, etc. The experiment results showed that the detection accuracy for falling down of the soccer robot can be 98% and the stability duration can be 60 minutes.

• Periodical: Applied Mechanics and Materials (Volumes 513-517)
• Pages: 2851-2854
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.513-517.2851
• Online since: February 2014
• Authors: Xiao Fei Xu*
• Keywords: Attitude Detection, Cymbal Piezoelectric Composite Transducer, Robot, Sensitivity, Signal Processing, Stability Duration

References

[1] Aydin Dogan, Kenji Uchino, Robert E. Newnham. IEEE Transactions on Ultrasonics, Ferroelectrics, and Frequency Control. 1997，Vol. 44, No. 3：597~605.

DOI: 10.1109/58.658312

[2] Meegitt Sensing Systems. [J]. Power Engineering, 2011, 115(7): 79.

[3] Andreea Spineanu, Philippe Bénabès, Richard Kielbasa et al. [J]. Sensors and Actuators. A, Physical, 1997, A60/61(1/3): 127.

[4] J. E. Paul A. Wlodkowski, Kan Deng, Manfred Kahn et al. [J]. Sensors and Actuators. A, Physical, 2001, A90 (1-2): 125-131.

[5] LUCIENEYRAUD, BENOITGUIFFARD, DAVIDAUDIGIERetal. [J]. Ferroelectrics, 2008, 366(0): 37-44.

[6] Christian C. Hindrichsen, Ninia S. Almind, Simon H. Brodersen et al. [J]. Journal of electroceramics, 2010, 25(2/4) : 108.

[7] Minami I. [J]. Journal of oral rehabilitation, 2010, 37(8): 590-595.

[8] Wufa Liu etc. [J], sensor technology, 2005. 25 (3): 86-89.

[9] Denghua Li, Xiaofei Xu etc. Intelligent detection technology and instrument [M]. Beijing: Science Press, (2012).

[10] Denghua Li, Xiaofei Xu et al, New piezoelectric composite transducer and application [M]. Beijing: Science Press, (2007).

[11] Xiaofei Xu, Denghua Li. Journal of Scientific Instrument 2006, 26 (6): 1598～1600.
