A Study of Airborne Antennas Radiation and Mutual Coupling

Abstract:

Radiation characteristics and mutual coupling are the important factors to the integration design and arrangement for airborne antennas. And the study of them is significant to the EMC of airborne electronic systems. Therefore, by using UTD, a study of predicting the far field pattern of a monopole mounted on the fuselage of an aircraft is described, and the method of computing isolation between airborne antennas is referred to. Initially simple model of large airplane is given by the principle that configuration should be simplified while electromagnetic radiation characteristics should not be neglected. Furthermore, single order, two orders as well as higher orders ray tracing are discussed based on the basic modals such as cylinder, taper and flat. The analytical solution of ray tracing is given out when it exists. If the analytical solution of ray tracing doesnt exist, faster numerical searching method is recommended. Then shadow judgment is introduced briefly. Lastly programs are made, and the results are proved true by comparing them with relative referencesv [1].

• Periodical: Applied Mechanics and Materials (Volumes 513-517)
• Pages: 2943-2946
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.513-517.2943
• Online since: February 2014
• Authors: Hao Yang, Bo Nian Li*, Ning Luo, Si Rui Zhang, Shi Jie Zhang, Cheng Qiao Liu
• Keywords: Airborne Antenna, Isolation between Antennas, Radiation Pattern, Ray Tracing, UTD

References

[1] R.M. Jha D.J. Fdwards, and R. Bhakthavathsalam, Surface ray tracing solution of ellipsoid of revolution for UTD mutual coupling applications, Electronics Letters, 28, (1992).

DOI: 10.1049/el:19920230

[2] K.M. Jha S.A. Bokhari, and W. Wiesbeek, A novel ray tracing on general paraboloids of revolution for UTD applications, IEEE: Transaction on Antennas and Propagation. AP-41, (1991).

DOI: 10.1109/8.237625

[3] P. Moon and D.E. SPencer, Field Theory Handbook, Berlin, Springer-Verlag, (1971).

[4] P. H Pathak and N. Wang, Ray analysis of mutual coupling between antennas on a convex surface, IEEE: Transaction on Antennas and Propagation. AP-29, 1981, PP. 911-922.

DOI: 10.1109/tap.1981.1142682

[5] S.W. Lee, A review of GTD calculation of mutual admittance of slot conformal arrays., Electromagnetics, 2, (1982).

DOI: 10.1080/02726348208915159

[6] P. H Pathak, N. Wan, W.D. Burnside, and R.G. Kouyoumjian, A uniform GTD solution for the radiation from sources on a convex surface., IEEE: Transaction on Antennas and Propagation. AP-29, (1981).

DOI: 10.1109/tap.1981.1142636
