Research and Realization of Phased Array Radar Functional Simulation System

Abstract:

In order to diminish the simulation granularity of phased array radar simulation system, modeling the target track is really necessary. This paper adds the target track simulation module and coordinate conversion module to the original functional simulation system of the phased array radar, thereby presents the frame construction, additional mathematical modules and simulate procedure of the improved simulation system. The phased array radars functional simulation system is proposed for the realization of the actual simulation software system. The simulation result verifies the efficiency of modeling method and mathematical modules.

• Periodical: Applied Mechanics and Materials (Volumes 513-517)
• Pages: 2954-2958
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.513-517.2954
• Online since: February 2014
• Authors: Yu Zhang*, Jun Wang
• Keywords: Functional Simulation, Phased Array Radar, Target Track Modeling

References

[1] Chen Guofa, Feng Bing. Radar System Simulation [J]. Journal of Radar and Confrontation, 1997 (3) : 6-11.

[2] Li Qinfu, Xu Xiaojian. Research on Simulation Model of Phased Array Radar System [J]. Journal of China Institute of Electronics, 2007, 2 (2) : 239-243.

[3] Wang Lu, XingQingHua. Improved Functional System Simulation of Phased Array Radar [J]. Modern Defense Technology, 2013 (001) : 164-169.

[4] Guo Jinliang, Zhang Yu, Wang Liandong, et al. Research and Realization of Shipborne Phased Array Radar Simulation System [J]. Journal of System Simulation, 2010, 22 (11) : 2571-2574.

[5] Xu Zhenlai. Phased Array Radar Data Processing [M]. Beijing: National Defence Industry Press, 2009. 4.

[6] He You, Xiu JianJuan, Zhang Jingwei, etc. Radar Data Processing With Applications (Second Edition) [M]. Beijing: Publishing House and Electronic Industry, 2009. 7.
