Design and Implementation of High-Precision Mine-Used Water-Pressure Sensor

Abstract:

A novel mine-used water-pressure sensor is presented in this paper, the configuration, working principle and design of main circuits are introduced in detail. Using pressure sensor, high precision 24 bits A/D converter AD7714 and low power consumption MCU P89LPC932 to complete the water-pressure measurement, and transferred the measuring results to upper computer through M-BUS, realized the stability measurement of high precision and low power consumption.

• Periodical: Applied Mechanics and Materials (Volumes 513-517)
• Pages: 3513-3517
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.513-517.3513
• Online since: February 2014
• Authors: Rui Xue Wang*, Na Zhang, Le Nian Xu
• Keywords: AD7714, Data Acquisition, M-Bus, P89LPC932, Pressure Sensor

References

[1] Shi Li-ping. The Monitoring and Prediction of Mining Water Inflow [M]. Xuzhou: China University of Mining and Technology Press, (2003).

[2] Zhao Xin-min. Theory and Design of The Intelligent Instrument [M]. Ha Er-bin: Ha Erbin Institute of Technology Press, (1995).

[3] He Li-min, Application Technique of Single Chip Microprocessors Collection [M]. Beijing: Beihang University Press, (2004).

[4] Lu Fen-lan, Liang Jie-shen, Yao Fu-jiang. Meter-bus and its application. [J]. Control Engineering of China, 2005(12): 152-154.

[5] Chang Dong-lai, Jiang Yi. Application of TSS721A for automatic meter reading system. [J]. Appling of Electronic Technology, 2000(8): 59-60.
