Saturation Model and Phase Recovering for Phase Measuring Profilometry

Abstract:

Phase measuring profilometry is a method of structured light illumination whose three-dimensional reconstructions are susceptible to error from intensity saturation. Phase error caused by intensity saturation of fringe patterns is studied in this work. A mathematical model is derived for recovering saturated intensity by means of other patterns without saturation, and thus we can decrease the phase error introduced by the saturation. Both simulation and experiment results show that the phase error arisen from intensity saturation can be efficiently suppressed with the proposed algorithm.

• Periodical: Applied Mechanics and Materials (Volumes 513-517)
• Pages: 3996-3999
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.513-517.3996
• Online since: February 2014
• Authors: Ji Rong Sun*, Wei Zou
• Keywords: Intensity Saturation, Phase Error, Phase Measuring Profilometry, Phase Recovering

References

[1] M. Halioua, H. Liu. Optical three-dimensional sensing by phase measuring profilometry. Opt. Lasers in Eng. Vol. 11 (1989), pp.185-215.

DOI: 10.1016/0143-8166(89)90031-6

[2] X. Su, G. von Bally and D. Vukicevic. Phase-stepping grating profilometry: utilization of intensity modulation analysis in complex objects evaluation. Opt. Commun. Vol. 98 (1993), pp.141-150.

DOI: 10.1016/0030-4018(93)90773-x

[3] F. Chen, G. Brown and M. Song. Overview for the three-dimensional shape measurement using optical method. Opt. Eng. Vol. 39 (2000), pp.10-22.

[4] H. Liu, W. Su, K. Reichard and S. Yin. Calibration-Based Phase-Shifting Projected Fringe Profilometry for Accurate Absolute 3D Surface Profile Measurement. Optics Comm. Vol. 216 (2003), pp.65-80.

DOI: 10.1016/s0030-4018(02)02290-3

[5] C. Waddington and J. Kofman. Analysis of measurement sensitivity to illuminance and fringe-pattern gray levels for fringe-pattern projection adaptive to ambient lighting. Optics and Lasers in Engineering. Vol. 48 (2010), pp.251-256.

DOI: 10.1016/j.optlaseng.2009.07.001

[6] S. Zhang and S. Yau. High dynamic range scanning technique. Optical Engineering. Vol. 48 (2009), p.033604.

DOI: 10.1117/1.3099720

[7] W. Chen and Y. Li. Study of the influence of quantization on PMP measuring accuracy. Laser Journal. Vol. 29 (2008), pp.34-35.

[8] B. Zhao and Y. Surrel. Effect of quantization error on the computed phase-shifting measurements. Optical Society of America. Vol. 36 (1997), p.2070-(2075).

DOI: 10.1364/ao.36.002070

[9] E. Hu, Y. He and Y. Chen. Study on phase error with periodic wave behavior and a new algorithm in projected grating phase-shifting profilometry. Journal of Experimental Mechanics. Vol. 23 (2008), pp.345-352.

[10] E. Hu and Y. Li. Study of the phase-recovering algorithm for saturated fringe patterns in the projection grating phase-shifting profilometry. Acta Photonica Sinica. Vol. 39 (2010), pp.1137-142.

DOI: 10.3788/gzxb20103906.1137
